CPAR-08AE-14293 High-efficiency dual filter

Description

Parker CPAR-08AE-14293 High-efficiency dual filter

Overview

The Parker CPAR-08AE-14293 is a high-pressure dual-filter of the CPAR series produced by Parker Hannifin, a globally leading provider of motion and control technology. This product is specially designed for demanding industrial and mobile hydraulic applications. Its core function is to effectively filter contaminants in the hydraulic oil, protect downstream key hydraulic components (such as pumps, valves, cylinders, etc.), and significantly enhance the reliability and service life of the entire hydraulic system.

Its “dual connection” design enables the filter elements to be switched and replaced or maintained without shutting down the system, ensuring the continuity and efficiency of the production process. It is an ideal choice for many industrial fields that require 24-hour uninterrupted operation.

Core features and advantages

Uninterrupted operation and online maintenance
Dual design: Equipped with two independent filter chambers and a directional control valve. When a filter needs to be replaced or maintained, simply operate the reversing valve to switch to another filter for operation. The system pressure remains stable, achieving true non-stop operation.

◦ Bypass valve protection: The built-in bypass valve can automatically open when the filter element is completely blocked by contaminants, ensuring the continuous smoothness of the system oil passage and avoiding the interruption of system oil supply and equipment damage caused by filter element blockage.

2. Outstanding filtration performance:
This model can accommodate high-performance Parker filter elements and achieve a filtration efficiency of up to β youdaoplaceholder8 (c)≥1000, meaning that the capture efficiency for particles of specific sizes exceeds 99.9%, significantly enhancing the cleanliness of the oil.

Different precision filter elements (such as 10μm, 25μm, etc.) are available as options to meet the strict requirements for oil purity in various application scenarios.

CPAR-08AE-14293

3. Robust and durable structure
The main body is made of high-strength steel, which has undergone precise processing and strict testing. It features high pressure-bearing capacity and excellent impact resistance and fatigue resistance.

The reliable sealing design ensures no leakage under high pressure and is suitable for extreme working conditions with a maximum working pressure of up to 420 bar.

4. Rich configuration options and visual indications
It can be equipped with a differential pressure transmitter (clogging alarm) (electrically controlled or mechanical type). When the pressure difference between the upstream and downstream of the filter element reaches the set value, a visual (pop-up indicator rod) or electrical signal (switch contact) will be sent out to remind the operator to replace the filter element in time.

It provides multiple port connection methods (such as SAE flange), facilitating system integration and installation.

5. Wide application compatibility
It is applicable to various industrial fluids such as hydraulic oil, lubricating oil, water glycol, etc.

Typical application fields

• Metallurgical machinery: Hydraulic systems with high energy consumption and high environmental pollution such as continuous casting machines, rolling mills, and presses.

• Mining machinery: Pressure filtration in the hydraulic circuits of mobile equipment such as rock drills, roadheaders, and hydraulic supports.

• Marine engineering: Deck machinery, steering gears, propulsion systems, etc.

• Power industry: Turbine control systems, hydraulic opening and closing systems for hydropower stations.

• Injection molding machine: The hydraulic system of large plastic injection molding machines.

• Others: Any critical hydraulic system that requires high pressure, high reliability and does not allow downtime for maintenance.

Technical Specification Summary (Based on General Characteristics of CPAR Series)

Model: CPAR-08AE-14293

• Series: CPAR dual filter

• Port size: Generally, “08” represents SAE 1-1/2″ port (please refer to the official information for details).

• Design pressure: Up to 420 bar (6000 psi)

• Flow range: Depending on the specific configuration and filter element, the CPAR-08 typically covers a medium to high flow range.

• Filter element model: It must be matched with the specified Parker dual filter element (such as 028 series or other compatible models).

• Transmitter pressure difference: Usually, 3.5 bar or 5 bar, etc. can be selected.
