Description
HONG KONG SAUL ELECTRICAL LIMITED, as an Eaton Authorized Distributor, delivers industrial-grade electrical components with UL and IEC compliance. Specializing in power distribution solutions, we ensure 99.9% availability for critical infrastructure worldwide.
Technical Specifications
Product Model | CS-TX3-3.81X2.54-64TW Manufacturer | Eaton Product Type | Pluggable Terminal Block Pitch | 3.81 mm Wire Size | 24-12 AWG Voltage Rating | 600 VAC/VDC Current Capacity | 20 A Continuous Material | Polyamide (UL94 V0) Contact Resistance | <2 mΩ Certifications | UL 1059, IEC 60947-7-1 Operating Temp | -40°C to +120°C Warranty | 1 Year Replacement
Key Features and Advantages
The CS-TX3-3.81X2.54-64TW features a tool-less push-in design enabling 50% faster wiring compared to screw terminals. Its dual-chamber contact system ensures vibration resistance up to 15g (IEC 60068-2-6). Transparent housing allows visual verification of wire seating, while integrated test points facilitate live circuit diagnostics. The flame-retardant material meets UL94 V0 standards for hazardous environments. Cross-compatible with Eaton’s XSeries® modular systems for flexible panel design.
CS-TX3-3.-81X2.54-64TW
Application Areas
Critical for PLC cabinet wiring, the CS-TX3-3.81X2.54-64TW ensures reliable signal transmission in manufacturing automation. Renewable energy systems utilize its -40°C rating for solar inverter connections. Transportation applications benefit from the vibration-resistant design in railway control panels. The 600VAC rating supports motor control center (MCC) installations in industrial plants.
Related Products
CS-TA3-5.0 (5.0mm Pitch Terminal Block)
XS6S-M12MS-4 (M12 Connector System)
1920100157 (End Cover for XSeries)
196452 (Jumpers for Bridging)
CS-EPI-3.81 (Plug-In Bridge Connector)
Installation & Maintenance
Installation preparation: Strip wires to 9-10mm length before inserting into CS-TX3-3.81X2.54-64TW. Use certified ferrule connectors for stranded wires. Maintenance recommendation: Email our team for annual contact resistance testing using 4-wire Kelvin method. Clean terminals with non-abrasive isopropyl alcohol wipes to prevent oxidation.
Product Assurance
Each CS-TX3-3.81X2.54-64TW undergoes 5000 insertion cycles testing with IEC 60947-7-1 validation. Our Critical Infrastructure Program guarantees 48-hour replacement for bulk orders. Legacy system upgrades include terminal block retrofits with preserved wire numbering schemes.
