Description
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | EUCFW110024T40FAZ |
| Manufacturer | WEG |
| Product Type | Compact Frequency Inverter |
| Input Voltage | 3-phase 380-480V AC ±10% |
| Output Power | 2.4 kW (3.2 HP) |
| Output Current | 5.5A continuous |
| Overload Capacity | 150% for 60 seconds |
| Switching Frequency | 4-16 kHz adjustable |
| Control Modes | V/f, Sensorless Vector, Torque Control |
| Communication Protocols | Modbus RTU, CANopen, Ethernet/IP |
| Digital Inputs | 4 programmable (24V) |
| Analog Inputs | 2 channels (0-10V/4-20mA) |
| Relay Outputs | 1 programmable (250V/2A) |
| Braking | Integrated dynamic braking |
| Protection Rating | IP20 |
| Operating Temperature | -10°C to +50°C |
| Dimensions | 150 x 180 x 165 mm |
| Certifications | CE, UL, cUL |
Key Features and Advantages
The WEG EUCFW110024T40FAZ compact frequency inverter delivers robust motor control for industrial applications with its 2.4kW output power and advanced sensorless vector control technology. Engineered for efficiency, its integrated EMC filter ensures compliance with electromagnetic compatibility standards while reducing harmonic distortion. The inverter’s wide input voltage range (380-480V AC) provides flexibility for various power systems.
Advanced control capabilities: Featuring multiple control modes including V/f, sensorless vector, and torque control, the EUCFW110024T40FAZ adapts to diverse application requirements. Its 150% overload capacity for 60 seconds handles demanding start-up conditions, while the adjustable switching frequency (4-16 kHz) optimizes performance for specific motor types and noise requirements.
EUCFW110024T40FAZ
Comprehensive connectivity: With built-in Modbus RTU, CANopen, and Ethernet/IP protocols, the EUCFW110024T40FAZ seamlessly integrates into industrial automation networks. The inverter features four programmable digital inputs, two analog inputs, and one relay output for flexible system integration. Its intuitive keypad with LCD display simplifies parameter configuration and provides real-time monitoring of operational data.
Protection features: Comprehensive safeguards include overvoltage, undervoltage, overload, short-circuit, and overtemperature protection. The EUCFW110024T40FAZ includes integrated dynamic braking for rapid deceleration without external resistors. Its automatic motor adaptation feature simplifies commissioning by automatically identifying motor parameters.
Energy efficiency: The inverter’s Eco mode optimizes energy consumption during light-load conditions, reducing power consumption by up to 30%. Its built-in PID controller enables closed-loop process control for applications like pumps and fans. The compact design saves panel space while maintaining full functionality for motor control applications up to 3.2 HP.
Our Drive Solutions Expertise
As industrial automation specialists, we provide comprehensive drive solutions including selection, configuration, and commissioning services. Our engineers offer application support for motor control systems across various industries.
All WEG products include 1-year warranty with technical support. For application assistance with the EUCFW110024T40FAZ, email our engineering team for personalized consultation.
