Description
Product details:
The Fireye 95UVS2-1 Enhanced Model InSight Scanner – Ultra-violet with quick disconnect. FM, CSA Approved.
The Fireye InSight Type 95 flame scanners incorporate an internal flame relay with adjustable ON/OFF thresholds, thereby eliminating the need for a remote flame amplifier. All Fireye inSight scanner models are powered by 24 Vdc, have either a twelve-pin electrical quick disconnect or 10 ft. cable (“CG” models), and contain electronic self-checking (no mechanical shutter required). The scanners contain an eight-character alpha-numeric LED display and a four push-button keypad to enable the user to view operating parameters and select setpoints.
95UVS2-1
Type 95IR contains an infrared flame sensor, responding to infrared radiation from 700 to 1700
nanometers wavelength. This sensor is best suited to coal and oil applications.
Type 95UV contains an ultraviolet flame sensor, responding to ultraviolet radiation from 295 to 320
nanometers wavelength. This sensor is best suited to gas applications.
Type 95DS (Dual sensor) contains both the infrared and ultraviolet flame sensors described above.
This sensor is best suited to multi-fuel applications.
The Standard Model S1 is best suited to the many applications that do not require the level of
sophistication, or the remote communications capability of the Expanded Model S2 (e.g. single
burner boilers and furnaces, duct burners, etc.)
The Expanded Model S2 is best suited to the applications that require the highest level of sophistication and flexibility (addition choices of modulation frequencies, and the time-saving AutoTune
function), and remote communications capability (e.g. larger multi-burner boilers and furnaces).
