PARKER COMPAX 2500S/F3 Servo Drive​

Description

​​Product Overview: PARKER COMPAX 2500S/F3 Servo Drive​​

The ​​PARKER COMPAX 2500S/F3​​ is a compact yet powerful ​​digital servo drive​​ designed for precise motion control in industrial automation applications. Part of Parker Hannifin’s established ​​COMPAX 3​​ series, this drive combines advanced control capabilities with user-friendly configuration tools to deliver high dynamic performance for brushless servo motors. The “​​S/F3​​” suffix indicates specific firmware and functionality tailored for speed and torque control, making it ideal for applications requiring rapid response, accuracy, and reliability.

Engineered for seamless integration into diverse motion systems, the COMPAX 2500S/F3 supports standalone operation or integration into multi-axis networks, providing flexibility for both simple and complex automation tasks.

​​Key Features & Benefits​​

​​High Dynamic Performance​​:
Offers precise control of speed and torque with fast response times, ensuring accurate motion profiles for demanding applications such as packaging, printing, and robotics.

​​Compact Design​​:
Space-efficient form factor allows for high-density mounting in control cabinets, optimizing panel space without compromising power output.

​​Integrated Control Modes​​:
Supports multiple operating modes including ​​speed control​​, ​​torque control​​, and ​​position control​​ (with optional firmware), enabling adaptability to various motion requirements.

​​Fieldbus Connectivity​​:
Features built-in support for popular fieldbus protocols such as ​​CANopen​​, ​​DeviceNet​​, and ​​EtherCAT​​ (dependent on firmware version), facilitating easy integration into PLC-based automation systems.

​​Advanced Tuning and Diagnostics​​:
Includes automatic tuning algorithms and real-time diagnostics via Parker’s ​​Parker IQ​​ or ​​Motion Planner​​ software, simplifying commissioning and troubleshooting.

​​Safety Features​​:
Complies with industry safety standards (e.g., SIL 2/3) with optional safe torque off (STO) and other safety functions to protect operators and equipment.

PARKER COMPAX 2500S/F3

​​Technical Specifications​​

​​Typical Applications​​

• ​​Packaging Machinery​​: Control of fillers, cappers, and labeling systems.
• ​​Printing and Converting​​: Precision web tension control and registration.
• ​​Automated Assembly​​: Rotary index tables and pick-and-place systems.
• ​​Textile Machinery​​: Spindle control and winding applications.
• ​​Medical Devices​​: Precision motion in diagnostic and fluid handling equipment.

​​Integration & Configuration​​

​​Motor Compatibility​​:
Designed to operate with Parker’s BLS series brushless servo motors or third-party motors with compatible feedback.

​​Standalone or Networked Operation​​:
Can function as a standalone drive or as part of a multi-axis network via fieldbus communication.

​​Software Tools​​:
Configured and tuned using Parker’s ​​Parker IQ​​ software, which provides parameterization, motion profiling, and real-time diagnostics.

​​Why Choose the PARKER COMPAX 2500S/F3?​​

• ​​Precision and Reliability​​: Delivers high accuracy in speed and torque control for critical automation tasks.
• ​​Ease of Use​​: Intuitive software tools reduce commissioning time and simplify maintenance.
• ​​Flexibility​​: Supports a wide range of applications through configurable operating modes and fieldbus options.
• ​​Compact Power​​: High power density in a small footprint, ideal for space-constrained installations.

​​Disclaimer​​:
Specifications may vary based on firmware version and hardware revision. Always refer to the official ​​Parker COMPAX 3 Series Documentation​​ for detailed technical and safety guidelines. Installation and commissioning must be performed by qualified personnel.
