Description
Product Overview
The Concurrent SSI232.1 029.365.083 is a high-performance simulation and real-time interface module designed for aerospace, defense, and industrial automation applications. Part of Concurrent’s SSI (Simulation Systems Interface) series, this device enables deterministic data acquisition and signal processing for flight simulators, hardware-in-the-loop (HIL) testing, and autonomous system validation. The Concurrent SSI232.1 029.365.083 integrates multi-protocol I/O channels with ultra-low latency, supporting critical tasks such as sensor emulation, actuator control, and real-time data logging. Its ruggedized design and MIL-STD-810G compliance ensure reliable operation in extreme environmental conditions, including high vibration, shock, and wide temperature ranges.
Engineered for precision, the Concurrent SSI232.1 029.365.083 features FPGA-based processing and time-stamping accuracy of ±1 µs, making it indispensable for synchronizing distributed systems in complex test benches. With native support for ARINC-429, MIL-STD-1553, and Ethernet protocols, this module seamlessly interfaces with avionics, flight control systems, and radar emulators. As a cornerstone of Concurrent’s real-time ecosystem, the Concurrent SSI232.1 029.365.083 accelerates development cycles while ensuring compliance with DO-178C and FACE™ standards for safety-critical applications.
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | Concurrent SSI232.1 029.365.083 |
| Manufacturer | Concurrent |
| Product Type | Real-Time Simulation Interface Module |
| Processor | Xilinx Ultrascale+ FPGA |
| I/O Protocols | ARINC-429, MIL-STD-1553, CANbus, Ethernet/IP |
| Channels | 32 ARINC-429 (Tx/Rx), 4 MIL-STD-1553 buses, 8 CAN FD |
| Latency | < 2 µs (FPGA-to-FPGA) |
| Time Synchronization | IEEE 1588 PTP (Precision Time Protocol) |
| Operating Temperature | -40°C to +85°C |
| Power Supply | 24 VDC ±10%, 50 W max |
| Certifications | MIL-STD-810G, DO-178C, RoHS |
| Data Storage | 64 GB onboard NVMe SSD |
| Dimensions | 200 mm x 150 mm x 40 mm |
| Weight | 2.1 kg |
SSI232.1-029.365.083
Key Functional Features
The Concurrent SSI232.1 029.365.083 delivers unmatched performance in real-time simulation:
- Deterministic Processing: FPGA-executed logic ensures sub-microsecond jitter for time-critical tasks.
- Multi-Protocol Integration: Simultaneous handling of avionics, military, and industrial communication standards.
- Ruggedized Construction: Conformal coating and shock-mounted components withstand 15g vibration and 40g shock.
- Precision Timing: IEEE 1588 PTP synchronization across distributed systems for coherent data capture.
- Custom Signal Conditioning: User-programmable FPGA logic for bespoke signal routing and filtering.
For scalability, the module supports daisy-chaining via fiber-optic links, enabling multi-node synchronization in large-scale test environments.
Application Scenarios
The Concurrent SSI232.1 029.365.083 is critical in:
- Aerospace: Real-time flight control system testing with ARINC-429/MIL-STD-1553 avionics emulation.
- Defense: HIL validation of unmanned vehicles and radar systems under MIL-STD-810 conditions.
- Automotive: Autonomous driving sensor simulation with CAN FD and Ethernet/IP integration.
- Energy: Grid protection relay testing with synchronized fault injection and response analysis.
- Industrial Robotics: Deterministic motion control and feedback for collaborative robot systems.
Related Products
- Concurrent SSI240.2: High-channel-count analog I/O module for sensor emulation.
- Real-Time Horizon OS: Deterministic OS for SSI232.1 integration.
- MIL-STD-1553 Test Suite: Compliance validation software for military buses.
- ARINC-825 CANbus Gateway: Protocol converter for legacy avionics systems.
- Concurrent SimWorks: Scenario generation and analysis toolkit.
Product Assurance
Concurrent guarantees the Concurrent SSI232.1 029.365.083 with a 10-year product lifecycle and DO-178C Design Assurance Level (DAL-A). Each unit undergoes 500-hour burn-in testing, EMI/EMC validation (MIL-STD-461), and thermal cycling per MIL-STD-810. Global customers receive 24/7 support via Concurrent’s Real-Time Response Team, including FPGA logic customization and firmware updates. The module is backed by a 5-year warranty, extendable through Concurrent’s TotalCare program, covering calibration, obsolescence management, and cybersecurity hardening.
