XV-440-10TVB-1-13-1 EATON Touch Screen

Product details:

XV-440-10TVB-1-13-1 EATON Touch Screen, Infrared, 24 Volt DC, 10.4z, tft Color, Ethernet, RS232, CAN, (PLC)

User interface, XV400, Product range :XV400 10.4 “, Features :HMI-PLC (PLC modified by user), common features of model series: Ethernet interface, USB device, RS232, CAN/easyNet, UL508, cUL approved, PLC features can be installed by user, Communication range can be installed by user using license, display type: Color display, TFT, touch technology: Infrared touch, color quantity: Adjustable :65536 or 256 colors, resolution :VGA, 640 x 480 Operating system :Windows CE(license required), CompactFlash card required, Plc-license: User Can install LIC-PLc-MXP-media 140390, license certificate for on-board interface: Can be extended as required, see attachment -%3E License Product Certificate, built-in interface :1 Ethernet 100base-TX/10base-T, 1 RS232, 1 Can, 2 USB host, 1 USB device, Front type: Standard front, with standard film, laminated safety glass, non-reflective, Purpose: Embedded mounting, Slot: For compact memory card Automation: Required, see attachment -%3E memory card, Plugable communication card (optional): Yes, Heat loss: 32W, Protection grade (IEC/EN 60529, EN50178, VBG 4): IP65(front), IP20(back)

Touch screen system generally includes two parts: touch detection device and touch screen controller. The touch detection device is installed in front of the display screen to detect the user’s touch position and then transmit the information to the touch screen controller. The main function of the touch screen controller is to receive the touch information from the touch point detection device, and convert it into contact coordinates, judge the meaning of the touch and then send to the PLC, it can also receive the command sent by the PLC and execute, such as dynamic display switch quantity and analog quantity
