Description
Product details:
The CLX-APACS module enables ControlLogix / Plant-PAx™ systems to control Moore/Siemens APACS+ IO Bus remote I/O racks. This provides the ability to perform a phased migration of legacy Moore APACS DCS systems.
Features and advantages of CLX-APACS
Monitor Mode – Allows real-time testing of the execution of the ControlLogix program against the ACM controller program
Master Mode – Allows the user to remove the APACS+ ACM controller and control the process from the ControlLogix PLC
Supports all standard APACS+ digital and analog I/O modules
Each network segment supports up to 39 IO bus cards
Automatic import of current APACS+ I/O configuration from Siemens 4-mation software’s object file
Configuration files are downloaded to the module via RSLinx™ Classic
Auto-configuration feature maps APACS+ I/O data to tags in the ControlLogix processor
Supports up to 4464 discrete points, or up to 1116 analog points, or any combination thereof
Diagnostic data from APACS+ network mapped to ControlLogix processor
Multi-color LEDs to indicate APACS+ network connection status
Hardware Specifications
Specification | Description |
Ports | Dual Channel, Redundant Serial RS-485 |
Typical Power Consumption | 5 mA @ 24 VDC and 450 mA @ 5.1 VDC |
Maximum Power Dissipation | 2.5W |
Operating Temperature | 32°F to 140°F (0 ºC to 60 ºC) |
Storage Temperature | -40°F to 185°F (-40 ºC to 85 ºC) |
Humidity | 5% to 95% RH, with no condensation |
