140ARI03010 ANALOG INPUT- 8 I NI / PT 100
Product description
Enhancing Connectivity: The Schneider Electric 140ARI03010 I/O Module
Manufacturer: Schneider Electric
Schneider Electric introduces the 140ARI03010, an advanced I/O module designed to streamline data acquisition and enhance connectivity in industrial automation systems. With Schneider Electric’s commitment to innovation and reliability, this module offers precision and versatility to meet the diverse needs of modern manufacturing.
Versatile Module Format: Standard Design
The 140ARI03010 features a standard module format, ensuring compatibility with a wide range of industrial control systems. Its versatile design allows for seamless integration into existing setups, simplifying installation and configuration processes.
Expanded Input Capacity: 8 Analogue Inputs
Equipped with 8 analog input channels, the 140ARI03010 provides ample capacity for monitoring various process parameters. Whether measuring temperature, pressure, or voltage, this module offers flexibility to accommodate diverse input signals.
Precision Input Handling: Temperature Probe Compatibility
The 140ARI03010 supports a range of temperature probes, including Pt 100, Pt 200, Ni 100, and Ni 200 types, ensuring precise temperature measurement across different temperature ranges. With its high-resolution analog input (13 bits) and low input impedance (>= 10 MOhm), this module delivers accurate and reliable data acquisition.
Robust Isolation and Signal Integrity
With built-in isolation between channels and the bus, the 140ARI03010 ensures signal integrity and protection against electrical interference. Its robust isolation capabilities (1780 V AC, 2500 V DC) provide peace of mind in demanding industrial environments, minimizing the risk of signal distortion or equipment damage.
140ARI03010140ARI03010
Product parameter
| Part Number | 140ARI03010 |
| Manufacturer | Schneider Electric |
| Type | I/O Modules |
| Model # | 140-ARI-030-10 |
| Warranty | 2 Year |
| Module format | Standard |
| Analogue input number | 8 |
| Input type | Differential |
| Addressing requirement | 9 input words |
| Analogue input type | Temperature probe 2.5 mA Pt 100, Pt 200, Ni 100, Ni 200 |
| Temperature probe 0.5 mA Ni 100, Ni 200, Ni 500, Ni 1000 | |
| Temperature probe – 60…180 °C Ni 100, Ni 200, Ni 500, Ni 1000 |
Application field
Efficient Fault Detection and Signalling
Featuring local signaling indicators, including 8 LEDs for channel status (red/green), 1 LED for external fault detection (red), and 1 LED for bus communication status (green), the 140ARI03010 enables quick and efficient fault detection and troubleshooting. This enhances operational efficiency and minimizes downtime by facilitating prompt corrective actions.
Technical Specifications at a Glance
Module Format: Standard
Analog Input Number: 8
Input Type: Differential
Analogue Input Resolution: 13 bits
Absolute Accuracy Error: 0.1°C
Linearity Error: +/- 0.5°C, +/- 0.01% full scale
Isolation: 1780 V AC (channels and bus), 2500 V DC (channels), 300 Vrms AC (channels)
Update Time: 640 ms (2 wires/4 wires), 1200 ms (3 wires)
Fault Type: Overtaking scale, Broken wire
Power Dissipation: 1 W
FAQ
What type of temperature probes are compatible with the 140ARI03010?
The 140ARI03010 supports various temperature probe types, including Pt 100, Pt 200, Ni 100, and Ni 200, across a wide temperature range, ensuring versatile temperature monitoring capabilities.
What is the update time for the 140ARI03010 module?
The update time for the 140ARI03010 varies depending on the wiring configuration, with options for 640 ms (2 wires/4 wires) and 1200 ms (3 wires), providing flexibility to meet different application requirements.
What fault detection capabilities does the 140ARI03010 offer?
The 140ARI03010 can detect overtacking scale and broken wire faults, allowing for efficient troubleshooting and maintenance.
What is the power consumption of the 140ARI03010 module?
The 140ARI03010 has a low power dissipation of 1 W, ensuring energy efficiency and minimizing heat generation.
What is the bus current requirement for the 140ARI03010?
The 140ARI03010 requires a bus current of 200 mA for operation, ensuring compatibility with standard industrial communication networks.
