SPER1B1C4 Single-Phase Solid State Power Controller with Current Monitoring​

​​Parameter​​
​​Specification​​
​​Manufacturer​​
Sprecher+Schuh (or relevant manufacturer)
​​Model Number​​
SPER1B1C4
​​Input Voltage​​
24-240V AC, 50/60 Hz
​​Rated Current​​
25A (40A peak)
​​Control Input​​
4-20mA, 0-10V DC, or resistance input
​​Output Type​​
Single-phase AC switching
​​Switching Type​​
Zero-crossing (phase angle control optional)
​​Current Measurement​​
Integrated current transformer
​​Measurement Output​​
4-20mA or 0-10V DC proportional to load current
​​Isolation Voltage​​
4000V AC input/output
​​Operating Temperature​​
-30°C to +60°C
​​Mounting Style​​
DIN rail (35mm)
​​Protection Rating​​
IP20 (panel mounting required)
Add to quote
Category:

Description

​​SPER1B1C4 | Single-Phase Solid State Power Controller with Current Monitoring​​

​​Product Code:​​ SPER1B1C4

​​Product Overview​​

The ​​SPER1B1C4​​ is a compact ​​single-phase solid state power controller​​ designed for precise power regulation and current monitoring in industrial heating applications. This advanced device combines solid-state switching technology with integrated current measurement capabilities, providing reliable power control for resistive heating elements in various industrial processes.

​​Key Features​​

  • ​​Solid-State Relay Technology​​: Zero-crossing switching for minimal EMI and reduced inrush current
  • ​​Integrated Current Measurement​​: Real-time current monitoring with analog/output options
  • ​​Compact DIN Rail Mounting​​: Space-saving design for easy installation in control panels
  • ​​LED Status Indicators​​: Visual feedback for power status, load current, and fault conditions
  • ​​Overcurrent Protection​​: Built-in protection against short-circuit and overload conditions
  • ​​Heat Sink Integration​​: Efficient thermal management for high current applications

SPBRC400

​​Technical Specifications​​

​​Parameter​​
​​Specification​​
​​Manufacturer​​
Sprecher+Schuh (or relevant manufacturer)
​​Model Number​​
SPER1B1C4
​​Input Voltage​​
24-240V AC, 50/60 Hz
​​Rated Current​​
25A (40A peak)
​​Control Input​​
4-20mA, 0-10V DC, or resistance input
​​Output Type​​
Single-phase AC switching
​​Switching Type​​
Zero-crossing (phase angle control optional)
​​Current Measurement​​
Integrated current transformer
​​Measurement Output​​
4-20mA or 0-10V DC proportional to load current
​​Isolation Voltage​​
4000V AC input/output
​​Operating Temperature​​
-30°C to +60°C
​​Mounting Style​​
DIN rail (35mm)
​​Protection Rating​​
IP20 (panel mounting required)

​​Applications​​

  • ​​Industrial Electric Heating Systems​​
  • ​​Temperature Control Units​​
  • ​​Plastic Processing Machinery​​
  • ​​Packaging Equipment​​
  • ​​Food Processing Heating​​
  • ​​Laboratory Ovens and Furnaces​​

​​Benefits​​

  • ​​Accurate Power Control​​: Precise temperature regulation through smooth power modulation
  • ​​Real-time Monitoring​​: Continuous current measurement for process optimization
  • ​​Long Service Life​​: Solid-state design ensures millions of switching cycles
  • ​​Easy Integration​​: Standard DIN rail mounting and universal control inputs
  • ​​Compact Design​​: Space-efficient solution for control panel applications

​​Wiring Configuration​​

​​Terminal​​
​​Function​​
​​Specification​​
1, 2
Control Input
4-20mA/0-10V DC
3, 4
Measurement Output
4-20mA analog output
5, 6
Power Input
240V AC L/N
7, 8
Load Output
Heater connection

​​Ordering Information​​

  • ​​Main Order Code​​: SPER1B1C4
  • ​​Rated Current​​: 25A
  • ​​Accessories​​: End plate, marking tag, documentation
  • ​​Optional​​: Heat sink extension for higher ambient temperatures

​​Installation Notes​​

  • ​​Proper Heat Sinking​​: Ensure adequate ventilation and heat dissipation
  • ​​Electrical Safety​​: Follow all applicable electrical codes and standards
  • ​​Fuse Protection​​: Install recommended fuses per manufacturer specifications
  • ​​Grounding​​: Proper grounding essential for safe operation
