The G448-0002.V1 is an ULTRA SLIMPAK® DIN rail mount bridge input Field-configurable Isolator with 1800VDC isolation between input, output and power. The field configurable input and output offer flexible, wide ranging capability for bridge or strain gauge input applications from 0.5mV/V to over 50mV/V. Wide ranging, precision zero and span pots allow 50% adjustability of offset and gain within each of the 11 switch selectable input ranges. The output can be set for either 0 to 5V, 0 to 10V, 0 to 1mA, 0 to 20mA or 4 to 20mA.
Ultra slim housing for high density installations
ASIC technology for enhanced reliability
Applications
Signal Processing

eurotherm controls g448-0002.v1
