BENTLY 136188-02 Modbus I/O Module

136188-02 is an Ethernet/RS232 Modbus I/O Module developed by Bently Nevada. This component includes the Firmware Upgrade Kit (126M4118-01). It is a part of 3500/92 Communication Gateway module. The 3500/92 Communication Gateway module offers extensive serial (RS232/RS422/RS485) and Ethernet TCP/IP communication capabilities for the integration of all rack monitoring values and statuses with process control and other automation systems. Additionally, it enables Ethernet communication with the data acquisition software and 3500 Rack Configuration Software.

Characteristics

Power Consumption
5.6 watts typical with Modbus RS485 I/O Module

Operating Temperature
-30 °C to +65 °C (-22 °F to +149 °F)

Storage Temperature
-40 °C to +85 °C (-40 °F to +185 °F)

Dimensions
(Height x Width x Depth) 241 mm x 24.4 mm x 99.1mm (9.50 in x 0.96 in x 3.90 in)

Weight
0.44 kg (0.96 lb.)
