Description
3BSE042238R1 ABB Perform the following steps to install an internal Compact Flash card in the operator
panel:
1. Turn off the power to the panel.
2. Remove the back cover on the operator panel, using a torx screwdriver
(T10*50).
3. Flip the back cover; the CPU board is mounted inside the back cover.
Observe precautions for handling electrostatic sensitive devices.
Caution – If the CPU card and power card is disconnected from each other for a
longer period of time, the panel may not boot when it is reassembled again. To
remedy this problem, a hardware reset needs to be performed by setting the mode
switch 3BSE042238R1
Insert the Compact Flash memory card in its slot on the CPU board.
5. Re-attach the back cover to the operator panel.
6. Turn on the power to the operator panel.
7. When the operator panel starts up, you will be asked if you like to move the
files to the internal card; select YES to this question
Settings in Panel Builder3BSE042238R1
The size of the internal memory card must be entered in the configuration tool for
the operator panel.
1. Select Setup/Terminal Options.
2. Enter the size of the internal memory card under Memory card
settings/Internal.
