57310001-KD  DSBC 172 Bus Supervision Board

ABB DSBC 172 57310001-KD

The DSBC172 bus repeater module is a device designed for industrial automation control

systems. Here are the main features of the module:

First of all, as a bus repeater, it can extend and control the bus communication range of the system,

support long-distance data transmission and ensure the stability of the signal.

Secondly, the module supports a variety of industrial automation bus protocols, such as Profibus, Modbus,

etc., which makes it easy to interconnect with various devices and systems.

In addition, the main function of the DSBC172 bus repeater module is to expand the network transmission

distance by re-transmitting or forwarding the data signal. It is the physical layer device of the OSI model,

which is responsible for transmitting information bit by bit on the physical layer of two nodes, completing the

function of copying, adjusting and amplifying signals, so as to extend the length of the network. When the power

of the signal transmitted on the line is gradually attenuated due to loss, resulting in signal distortion and reception

errors, the repeater can amplify the attenuated signal to ensure that the signal is consistent with the original data.

Finally, the repeater module has a wide range of applications in the field of industrial automation, which helps

to improve the communication efficiency and stability of the system.
