Description
ABB CI871AK01 3BSE092693R1
(PROFIBUS DP-V1 Communication Interface for Industrial Automation Systems)
Product Overview
The ABB CI871AK01 3BSE092693R1 is a PROFIBUS DP-V1 communication interface module designed for ABB’s AC 800M controllers and S800 I/O systems. Part of ABB’s 800xA and Advant® OCS automation platforms, this module enables seamless integration of field devices (e.g., sensors, drives, valves) into industrial control networks. It supports high-speed data exchange and cyclic communication, making it essential for process automation in power plants, oil refineries, and manufacturing facilities.
Key Features
- PROFIBUS DP-V1 Protocol:
- Cyclic data exchange (up to 12 Mbps).
- Support for DP-V1 acyclic services (e.g., parameterization, diagnostics).
- Compatibility with PROFIBUS PA via segment couplers.
- Integration:
- Connects to AC 800M controllers (e.g., PM856, PM860) via S800 I/O bus.
- Configurable via Control Builder M or Engineering Station.
- Redundancy: Supports redundant PROFIBUS networks for fault-tolerant systems.
- Diagnostics: Built-in LED indicators for network status, errors, and power.
- Certifications: UL, CE, ATEX (for hazardous areas with appropriate enclosures).
Technical Specifications
| Parameter | Details |
|---|---|
| Communication Speed | 9.6 kbps to 12 Mbps (auto-negotiation) |
| Number of Nodes | Up to 125 devices per segment |
| Power Supply | 24 VDC (18–32 VDC range) |
| Operating Temp | -25°C to +70°C |
| Enclosure | IP20 (mounts on DIN rail in control cabinets) |
| Dimensions | 110 x 126 x 115 mm (WxHxD) |
| Weight | 0.5 kg |
CI871K01
Application Areas
- Power Generation: Integrates turbine control systems with field devices.
- Oil & Gas: Connects subsea valves and flow meters in offshore platforms.
- Chemical Processing: Links DCS systems to distributed I/O in batch plants.
- Manufacturing: Facilitates real-time data exchange in automated production lines.
Part Number Breakdown
- CI871: PROFIBUS DP-V1 communication interface series.
- AK01: Hardware revision and firmware variant.
- 3BSE092693R1: Unique ABB order code for procurement and lifecycle tracking.
Installation & Configuration
- Mounting: Secure to DIN rail in a control cabinet with proper spacing for ventilation.
- Wiring: Use shielded PROFIBUS cables (e.g., ABB CAB-148) with terminating resistors.
- Configuration:
- Define GSD files (device descriptions) in Control Builder M.
- Map I/O signals between AC 800M and field devices.
- Testing: Validate network health via PROFIBUS Analyzer Tools (e.g., Wireshark with PROFIBUS plugins).
Related Products
- CI854A: Ethernet TCP/IP communication interface for AC 800M.
- S800 I/O Modules: Remote I/O units (e.g., AI810, AO810) for signal conditioning.
- AC 800M PM866: Controller for logic execution and system coordination.
- ABB 800xA DCS: Distributed control system for holistic automation.
Why It Matters
The CI871AK01 bridges the gap between high-level control systems and field devices, ensuring reliable data flow in mission-critical applications. Its compliance with PROFIBUS standards guarantees interoperability with third-party devices, reducing integration complexity.
Product Assurance
- Warranty: 18-month standard warranty, extendable via ABB service agreements.
- Compliance: Meets IEC 61158 (fieldbus standards) and ISO 9001 quality requirements.
- Support: Access ABB’s 24/7 Global Technical Support for firmware updates and troubleshooting.
For detailed configuration, refer to ABB Document 3BSE032401R5101 or use the PROFIBUS GSD Repository. Always adhere to network design guidelines (e.g., topology, grounding) to ensure signal integrity.
