DX581-S ABB Safety Digital In./Output Module

DX581-S

DX581-S

DX581-S

DX581-S

DX581-S

• ABB Type Designation:DX581-S

• CN8:85389091

• Country of Origin:Germany (DE)

• Customs Tariff Number:85389091

• Delay Time (τ):1 … 500 ms

• EAN:4016779681803

• EPLAN Catalog Tree:Electrical engineering / PLC / General

• ETIM 7:EC001419 – PLC digital I/O-module

• ETIM 8:EC001419 – PLC digital I/O-module

• Gross Weight:0.159 kg

• Input Current:7 mA

• Input Voltage Type:DC

• Invoice Description:DX581-S:S500,Safety Dig.I/O Mod.8SDI8SDO

• Made To Order:No

• Maximum Input Voltage:0 … 30 V

• Maximum Order Quantity:60 piece

• Minimum Order Quantity:1 piece

• Number of Digital Configurable I/Os:8

• Number of Digital Inputs:8

• Number of Digital Outputs:8

• Order Multiple:1 piece

• Output:Transistor

• Output Current:0.5 A

• Output Voltage Maximum:20.4 … 28.8 V

• Output Voltage Type:DC

• Product Main Type:DX581

• Product Name:Distributed Automation I/Os

• Product Net Height:76 mm

• Product Net Length:62 mm

• Product Net Weight:0.13 kg

• Product Net Width:67.5 mm

• Product Type:PLC-AC500

• Quote Only:No

• SCIP:5916c970-096a-4753-a46e-f309240b87af Germany (DE)

• Safety Integrity Level (SIL):2

• Selling Unit of Measure:piece

• Short Description:DX581-S:S500, Safety Dig.I/O Mod.8SDI/8SDO

• Stocked At (Warehouses):

  Menden, Germany
  Singapore, Singapore
  Hangzhou, China

• Supply Voltage:24 … 24 V DC

• UNSPSC:32151802

• WEEE B2C / B2B:Business To Business

• WEEE Category:5. Small Equipment (No External Dimension More Than 50 cm)

• eClass:27-24-22-02
