Description
Technical Description 1756-IB16：
The Allen-Bradley 1756-B16 is a Controllogix l/O module. This 16-point DC input module, with 8 points in each group, can be connected to the 1756 ControlLogix case. Compatible removable junction box housing or RTB is the 1756-TBNH 20-bit NEMARTB and 1756-TBSH 20-bit spring clamp RTB. Before installation, ensure that the compatible RTB is ready, and the 1756 chassis and power supply are properly installed and grounded.
Module 1756-B16 has a nominal input voltage of 24 V DC, and the voltage class is 12/24 V DC current. Its operating voltage range is 10 to 31.2 V DC, with a total floor power of 0.56 watts. The current consumption at 5.1 volts DC is 100 mA. At 24 volts, the current consumption is 2 milliamps. The module also has a maximum inrush current of 250 mA peak, which decays to 37% in 22 milliseconds without activation. Its isolation voltage is 250 volts continuously. The module has a power consumption of about 5.1 watts at 60 degrees Celsius and a heat dissipation of 17.39 BTU/ hour. The on-state current of the module ranges from 2.0 mah at 10 volt DC to 10 mah at 31.2 volt DC. In the off state, it has a maximum voltage of 5V and a maximum current of 1.5mA. Module input latency is up to 1 ms hardware latency plus user configurable filter time (0, 1, or 2 ms). It has a maximum hardware latency of 2 milliseconds plus user-configurable filter times (0, 1, 2, 9, or 18 milliseconds).
The Allen-Bradley 1756-B16 is a DC absorbing input module that operates at a nominal input voltage of 24VDC. The module is used for 24v DC input signals, but can also be used for AC input voltages if suitable insertion circuits or components are installed.
The module supports single stand and independent controller configurations and is suitable for smaller and less important applications. It can also be used in larger applications where a higher degree of criticality is involved, such as remote /O systems or distributed control systems (DCS).
This module can be used as a discrete input module for any ControlLogix configuration, even Allen-Bradley’s PlantPaX DCS platform. There is almost no limit to how many modules can be installed. The number of instances or installations depends on the memory capacity of the processor and the physical chassis or available slots used.
The 1756-B16 uses a detachable terminal lock that provides a modular means of terminating input signals. Can be replaced with RTB part number 1756-TBNH1756-TBSH. It has user-configurable state change properties for applications that require immediate action when an input signal changes to a specified state. State changes (COS) bypass the processor’s normal scan cycle for faster logical execution.
