1756-PA7585-265V Allen-Bradley ControlLogix Power Supply

Description

1756-PA7585-265V Allen-Bradley ControlLogix Power Supply

The 1756-PA75 is an Allen-Bradley Standard power supply. This module is installed on the dedicated power

supply slot, located at the left most side any ControlLogix chassis. The primary purpose of this power supply

is to deliver the necessary backplane power, used by each of the modules installed to the chassis. This backplane power

energizes the modules to enter operational state.

The 1756-PA75 must be supplied with an external power to operate. It is compatible with 85-264VAC

voltage range along a frequency of 47-63 Hz while the nominal input voltage are 120VAC / 240VAC. This power

supply has an output power rating of 75 W when operated at 0…+60 °C (+32…+140 °F) and current capacities of 4A at 3.3VDC; 13 A at 5.1VDC and 2.8 A at 24VDC.

1756-PA75

The 1756-PA75 is compatible with a variety of ControlLogix chassis such as 1756-A4, 1756-A7, 1756-A10,

1756-A13, 1756-A17 and of chassis series, particularly Series B and Series C. if operating input supply to the 1756-PA75

is suddenly interrupted, this standard power supply provides a hold-up time of 2 cycles @ 85V AC, 60 Hz 6 cycles @

120V AC, 60 Hz 20 cycles @ 220V AC, 60 Hz. Additionally, it has an isolation voltage of rating of 250V (continuous),

Reinforced Insulation Type, Power Input to Backplane Type tested at 3500V DC for 60 s.
