Description
Technical Description 1756-RMB:
Allen-Bradley 1756-RM is a ControlLogix redundant module. This module can only be used with the ControlLogix platform for controller redundancy. It manages the connection of two (2) identical controllers installed in the same rack with the same components and configuration. It provides redundant system monitoring and module health through embedded LED displays such as PRI, COM and OK.
The 1756-RM has been released as series A and b. The series is basically an enhancement of the previous series, however, the 1756-RM with different series can coexist in a redundant configuration. It is highly recommended that the same series be installed for maximum operability of redundant Settings. When used with the same series of redundant modules, speeds can reach 100 Mbps.
The 1756-RM comes with one (1) single-mode LC fiber connector. It requires the use of a 1756-RMCx redundant cable to synchronize the operation of the redundant controller pairs. The controller can be configured using the redundancy configuration tool to set the redundancy and the overall parameters of the module to be configured using the Studio 5000 Logix designer.
The module is compatible with 1756-A4, 1756-A7, 1756-A10, 1756-A13, 1756-A17 ControlLogix chassis, 1756-PA72, 1756-PA75, 1756-PB72, 1756-PB75 standard power supply and 1756-PA75R, 1756-PB75R, 1756-PSCA2 redundant power supply. It is a single slot module that can be installed into any available slot in the case. The redundant pair must have the same configuration as the pairing case.
The 1756-RM consumes 4 mA at 1.2VDC, 1.2 mA at 5.1VDC, and 120 mA at 24VDC.
The current consumption of the 1756-RM redundant module is 4 mA at 1.2 volt DC, 1.2 amps at 5.1 volt DC, and 120 mA at 24 volt DC. The device is installed in the case and can be fitted into any slot. The 1756-RM module has a power consumption of 9 watts and heat dissipation of 31 BTU per hour. This ControlLogix comes with an open case with a T4 temperature code. In terms of the physical characteristics of the module, it weighs about 0.29 kg or 0.64 LBS and is small in size. The 1756-RM module operates in a temperature range of 0 to 60 degrees Celsius (32 to 140 degrees Fahrenheit) and can be stored in a temperature range of -40 to 85 degrees Celsius (-40 to 185 degrees Fahrenheit). The unit is manufactured according to several industry standards, including ce, CSA, Ex, C-Tick, and C-UL-USA Standard Certification.
