Name: 1769-OF4 analog output module
Brand: ABB
Availability: InStock

1769-OF4 analog output module

The 1769-OB32 belong to the 1769 Compact I/O. This solid-state device is a discrete output sourcing

module that is manufactured by Allen-Bradley for use with CompactLogix Controllers as well as MicroLogix 1500 controllers.

The 1769-OB32 is a high-density module that is equipped with Thirty-Two (32) output channels, isolated

in Two (2) groups of Sixteen (16) channels. This module is practical for use in applications where a large

number of I/Os are existing, with limited panel space. This module occupies 1.5 slot of the CompactLogix

or MicroLogix 1500 chassis to allow maximizing supported module of a specific controller.

Add to quote

Category: Allen-Bradley

Mail：sales@xiongbagk.cn
Phone/Wechat/Whatsapp：+86 18059884797

Description

1769-OF4 analog output module

The Allen-Bradley 1769-OF4 module is an analog output module that produces voltage/current signals. This

module has Four (4) single-ended outputs, with an output voltage range of 0 to 10 volts and 0-20 mA. The modules

resolution is 15-bit unipolar/bipolar with a draw current of 120 mA at 5.1 Volts. The module’s maximum heat

dissipation rating of 2.86 Watts and a 3.8-millisecond interruption-enabled maximum conversion rate. The

1769-OF4 module has a 2.9-millisecond step response rating of 63% and a resistivity load of 0 to 600

Ohms of current or 1 KOhms; or greater of voltage.

The 1769-OF4 has a maximum inductive load of 0.1

mH of current load and 1.0 µF of voltage load. It has an accuracy margin of 0.5% (full scale at 25 degrees

Celsius), and an output ripple of +/- 0.05% at 0 to 50 kilohertz.
This analog output module has an accuracy drift of +/- 0.0086% (per degree Celsius) and a non-linearity

margin of +/- 0.05%. It also has a module error margin (at 0 to 60 degrees Celsius) of +/-0.8%, and

repeatability of +/-0.05%. The 1769-OF4 module has an output impedance of <1 MOhm for voltage

output and >1 MOhms for current output. The 1769-OF4 module has current circuit protection of up to

40 mA and protection against excess voltage. It has a power up/power down output response of less

than 1 millisecond and operational voltage rated at 30 Volts DC. It has a weight of 280 G (0.61 pounds)

and module dimensions of 118 by 35 by 87 millimeters (4.65 by 1.38 by 3.43 inches).
