1769-PA4 Allen-Bradley CompactLogix I/O power source

Description

1769-PA4 Allen-Bradley CompactLogix I/O power source

Allen-Bradley 1769-PA4 is a CompactLogix I/O power source. It can supply 120 to 240 volts of AC power and 24 volts of DC power to CompactLogix 1769-L3x processors, controllers, and I/O modules connected to them. The 1769-PA4 can be connected to up to 8 modules on each side and up to 16 modules on one power supply. This power supply provides 4A current at 5 volts DC or 2A current at 24 volts DC. The module measures 2.76×3.43 x 4.65 inches and weighs approximately 630 grams (1.39 pounds). The power supply supports DIN rail or panel mounting. It has an open housing with an integrated fuse that can be replaced with a fuse with part number Littelfuse 02183.15MXP or Wickman 19195-3.
Components of the 1769-PA4 include bus poles with locking function, LED status indicators, power doors with identification tags, removable and fixed bus connectors (with male and female pins), nameplate tags, upper and lower tongue slots, upper and lower DIN rail latches, terminal boards with finger safety covers, and housing covers for replaceable fuses.
The power supply has an optional input voltage range of 85 to 265 volts, an input frequency range of 47 to 63 Hertz, and a voltage range of 170 to 265 volts. Its power consumption is about 200 volt-amps at 120 volts AC, 240 volts at 240 volts AC, and a maximum surge current of 25 amps at 132 volts AC. The 1769-PA4 has a current capacity of 4 amps at 5 volt DC and 2 amps at 24 volt DC, and is rated for input voltage of 120 to 220 volts AC, wattages of 18 watts, and output voltage of 24 volts DC. From the AC power input to the system, its isolation voltage is 265 volts continuously.
The Allen-Bradley product with part number 1769-PA4 is a CompactLogix assembly used as a /O power supply. The CompactLogix /O power supply provides backplane power, which is allocated to the 1769Compact l/O module. The power supply provides power to the module from both sides of the device. Compact /O modules can be installed on each side of the I/O expansion power supply, up to eight (8) modules can be installed, for a total of 16 compact I/O modules.
The power supply has an optional voltage input range of 85 to 265 volts AC or 170 or 265 volts AC. Before energizing the power supply, ensure that the correct selection is activated to prevent damage to the module. The power supply module has A rated current output of 4.0A at 5v DC and 2.0A at 24v DC. The power supply is compatible in a CompactLogix component with a large number of discrete outputs and analog modules.
The power supply is fitted with an internal fuse. This fuse can be replaced with a fuse with part number Wickmann 19195-3.15A or Littelfuse 02153.15MXP.
Power planning is critical to building CompactLogix components because the power supply is the module referenced by the power distance rating requirements. This module requirement must be followed to maintain a valid CompactLogix configuration. Including the processor and communication module, no module shall exceed the specified power distance rating.
