1797-PS1E | Allen-Bradley | Flex Ex Power Supply

1797-PS1E | Allen-Bradley | Flex Ex Power Supply

 The Allen-Bradley 1797-PSIE is a Flex Ex Power Supply. This module has an input voltage range of 85-253 VAC with input frequency of 47-63 Hz. It has current consumption of 0.9 A with quad output ports with output power rating of 8.5 W each.

The Allen-Bradley 1797-PSIE is a Power supply module that is part of the 1797 Flex Ex product family. This module features an input voltage range of 85-253 VAC along an input frequency of 47-63 Hz. It has Four (4) output ports with each port delivers an output power rating of 8.5 W.

The 1797-PSIE has a flame proof enclosure with increased safety input/output terminations. Wire entry and exit ports of this module is sealed, having an M20 x 1.5 gland that is compatible with 6-12 mm (0.267…0.472 in.) wire diameter for the inputs and M16 x 1.5 gland that is compatible with 4-8 mm (0.157…0.315 in.) wire diameter for the outputs. Each output ports are Intrinsically-safe, galvanically isolated from the source and at the same time independently IS limited.

Category: Tags:

Description

DETAILS

1797-PS1E | Allen-Bradley | Flex Ex Power Supply

Manager:  Sunny

Email: sales@xiongbagk.cn (☜chick)

Skype: Sunny  |  Phone: 86-18059884797(WhatsApp)

1797-PS1E

1797-PS1E

1797-PS1E

1797-PS1E

1797-PS1E

Manufacturer Rockwell Automation
Thermal Dissipation 71.67 BTU/hr
Power Dissipation 21 W
Output Power 4 x 8.5 W
Current Consumption 0.9 A
Input Frequency 47…63 Hz
Voltage Range 85…253V AC
Input Connectors 85…253V AC, Um = 253V AC Terminals 1, 2, 4, 5 (earth symbol)
Part Number/Catalog No. 1797-PS1E

The Allen-Bradley 1797-PSIE is a Power supply module that is part of the 1797 Flex Ex product family. This module features an input voltage range of 85-253 VAC along an input frequency of 47-63 Hz. It has Four (4) output ports with each port delivers an output power rating of 8.5 W.

The 1797-PSIE has a flame proof enclosure with increased safety input/output terminations. Wire entry and exit ports of this module is sealed, having an M20 x 1.5 gland that is compatible with 6-12 mm (0.267…0.472 in.) wire diameter for the inputs and M16 x 1.5 gland that is compatible with 4-8 mm (0.157…0.315 in.) wire diameter for the outputs. Each output ports are Intrinsically-safe, galvanically isolated from the source and at the same time independently IS limited.

The 1797-PSIE comes with a protection factor of IP65. When the power supply outputs have been exposed to non-intrinsically safe signals, the 1797-PSIE, cannot be used in intrinsically safe installations. This module is applicable for installation in Zone 1 where the permissible ambient temperature is f -20…70 °C; Zone 22 that corresponds with the category 3D acc. to directive 94/9 EC and is marked with a type label accordingly. When used with an ambient temperature of 60 Degree Celsius, power supply leads must be designed for service temperature of 80 Degree Celsius.

When mounting this device, it is recommended to use star washers and nuts to establish reliable electrical connection. Where grounding bolts are installed, sub-panel paint or coating must be scraped to ensure continuous connection.

The 1797-PSIE supports daisy chain connection. This may be done if the total module power draw is less than 8.5 Watts. Otherwise, individual power supplies must be installed.
