2094-BM01-S kinetix6000 multi-axis servo drive

Product details:

Kinetix 6000 Multi-axis Drive 2094-BM01-S is an Asex module that connects directly to controlled devices via feedback cables. The shaft module is mounted on the power rail along with the integrated shaft module, control module, shunt module and other essential components that make up the Kinetix Drive motion control system.

Kinetix drive provides users with the ability to achieve synchronous motor motion control, commonly used in manufacturing machines. This drive system provides precise and synchronous control, enabling the motor and compatible motion equipment as one unit.

The 2094-BM01-S has A 400VAC class Axis module with A continuous current of 6.1 A and A peak current of 9.2A for the A Series and a 15.3 A drive for the B and C Series with a continuous power output of 3.9 kW. The efficiency is 98% and the short-circuit current rating is 200,000 A (rms) symmetrical. It has an integrated shunt with a sustained power of 50W and a peak power of 5.6kW. The internal shunt resistor of the module has a resistance value of 115 ohms.
