3500/15 Bently Nevada height modules

Description

3500/15 Bently Nevada height modules

Xiamen Xiongba Electronic Commerce Co. LTD is a World-Wide international Business Export Trade company by wholesale and Retail. We focus on Electronic & Industry Control & Network Products Area from Year 2006. Our Main Clients from North America, Europe, Middle East, South America and Asia – Countries: United States, UK, France, Spain, Mexico, Finland, Russia, Brazil, UAE, Canada, Germany, Italy, Peru, Sri lanka, India, Thailand, Vietnam, Singapore, Malaysia.

Can be transported to all parts of the world. (Exclude areas that cannot be transported under special circumstances! )

If necessary, please contact customer service.

The 3500/15 AC and DC Power Supplies are half-height modules and must be installed in designated slots on the left side of the rack. The 3500 rack can contain one or two power supplies with any combinations of AC and DC. Either supply can power a full rack. When two power supplies are installed in a rack, the one in the lower slot acts as the primary supply, and the other in the upper slot acts as the backup supply. If installed, the second supply is the backup for the primary one. Removing or inserting either power supply module does not disrupt operation of the rack as long as a second power supply is installed.
The 3500/15 AC and DC Power Supplies accepts a wide range of input voltages and converts them to voltages acceptable for use by other 3500 modules. The following power supplies are available with the 3500 Series Machinery Protection System: n Universal AC Power n High Voltage DC Power Supply n Low Voltage DC Power Supply

3500/15

3500/15

3500/15

3500/15

3500/15

Part Number Description
106M1079- 01 Universal AC Power Supply Module
106M1081- 01 Universal AC Power Input Module
129486-01 High Voltage DC Power Supply Module
129478-01 High Voltage DC Power Input Module
133292-01 Low Voltage DC Power Supply Module
133300-01 Low Voltage DC Power Input Module
01720025
Replacement Fuse (for both AC Power Input Module and High Voltage DC Power Input Modules)
01720045 Replacement Fuse (Low Voltage DC Power Input Module)
120M3877
Replacement Fuse Fast blow rated at 5A/500 Vac Size 6.3 x 32 mm (Universal AC Power Input Module)
129767-01 Power Supply Operations and Maintenance Manual
118M0915-01
Replacement connector for Universal AC Power Input Module
118M0915-02
Replacement connector for DC Power Input Module
