Description
Product Overview
The Bently Nevada 3500/54 133396-01 is a dual-channel speed monitoring module integral to machinery protection systems in critical industrial environments. As part of Bently Nevada’s 3500 Series, this module provides precise rotational speed measurement and overspeed protection for turbines, compressors, pumps, and other high-speed rotating equipment. The Bently Nevada 3500/54 133396-01 processes signals from proximity probes, magnetic pickups, or tachometers, delivering real-time speed data and triggering alarms or shutdowns to prevent catastrophic failures. Its dual-channel redundancy ensures continuous operation even during sensor or channel faults, aligning with SIL 2 safety standards (IEC 61508/61511) for critical applications.
Designed for seamless integration into 3500 racks, the Bently Nevada 3500/54 133396-01 supports dynamic speed measurement up to 50,000 RPM with ±0.1% accuracy. The module’s advanced diagnostics detect sensor health, signal integrity issues, and alignment errors, enabling predictive maintenance. With rugged construction and compliance with API 670 standards, it operates reliably in extreme temperatures (-40°C to +85°C) and high-vibration environments such as power plants, offshore platforms, and petrochemical facilities.
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | Bently Nevada 3500/54 133396-01 |
| Manufacturer | Bently Nevada (Baker Hughes) |
| Product Type | Dual-Channel Speed Monitor |
| Input Signals | Proximity probes, magnetic pickups, tachometers (5–30 Vrms) |
| Speed Range | 0–50,000 RPM |
| Accuracy | ±0.1% of reading |
| Outputs | 4–20 mA analog, relay alarms (trip/reset) |
| Response Time | < 10 ms |
| Power Supply | 24 VDC ±10% (redundant capable) |
| Operating Temperature | -40°C to +85°C |
| Certifications | SIL 2, API 670, ATEX/IECEx Zone 2 |
| Communication | 3500/92M Gateway for System 1® integration |
| Dimensions | 324 mm x 40 mm x 157 mm (rack-mounted) |
| Weight | 1.5 kg |
133396-01
Key Functional Features
The Bently Nevada 3500/54 133396-01 ensures operational safety and reliability through:
- Dual-Channel Redundancy: Independent processing of two sensors for fault tolerance and fail-safe operation.
- Advanced Signal Conditioning: Filters noise and compensates for signal degradation in harsh environments.
- Programmable Thresholds: Configurable overspeed, underspeed, and rate-of-change alarms via 3500 Rack Configuration Software.
- Diagnostic Alerts: Monitors sensor gap voltage, cable faults, and signal loss, triggering maintenance alerts.
- Phase Reference Input: Synchronizes with keyphasor signals for precise timing of speed-related events.
Application Scenarios
The Bently Nevada 3500/54 133396-01 is critical in industries requiring rigorous speed monitoring:
- Power Generation: Overspeed protection for gas/steam turbines and turboexpanders.
- Oil & Gas: Compressor and pump speed control in upstream and midstream operations.
- Petrochemical: Safeguards centrifugal compressors and gearboxes in ethylene plants.
- Marine: Monitors propulsion engines and auxiliary machinery on ships.
- Hydroelectric: Ensures stable operation of hydro turbines during load fluctuations.
Related Products
- Bently Nevada 3500/42M Proximitor® Module: Powers and conditions proximity probe signals.
- 3500/22M Transient Data Interface: Captures high-speed waveform data for diagnostics.
- 3300 XL 8mm Proximity Probes: Industry-standard sensors for speed and vibration monitoring.
- System 1® Software: Predictive analytics platform for machinery health management.
- 3500/93 Display Module: Local HMI for real-time parameter visualization.
Product Assurance
Bently Nevada guarantees the Bently Nevada 3500/54 133396-01 with a 5-year warranty, supported by ISO 9001-certified manufacturing. Each module undergoes HALT (Highly Accelerated Life Testing), EMI/EMC validation, and 500-hour operational stress testing. Global customers receive 24/7 technical support via Bently Nevada’s Machinery Health™ Centers, with on-site calibration and repair services available within 48 hours. Compliance with IEC 61508 and API 670 ensures adherence to global safety and machinery protection standards.
