5PC910.SX02-00  2-slot APC910 system unit

The APC910 system unit in slot 5PC910.SX02-002 is a highly compact industrial system unit designed for

integration into industrial environments. It has some remarkable features and functions, which make it widely

used in industrial automation, control and data processing.

First of all, from a structural point of view, the 5PC910.SX02-00 uses a special design that allows the device

to be directly integrated into the industrial environment to meet the needs of field applications. At the same time,

its compact design also saves valuable space, making installation and layout on industrial sites more flexible and convenient.

Secondly, in terms of electrical characteristics, the 5PC910.SX02-00 has a maximum nominal current of 5.5A and

a nominal voltage of 24VDC, which meets the high requirements for power supply stability in industrial sites. In

addition, it has a vibration storage capacity of 2-8Hz, ensuring stable operation in vibration environments.

In terms of functionality, the 5PC910.SX02-00 offers bus units with two PCI slots or one PCI and one PCIe slot,

which allows users to flexibly configure and expand the interface and functions of the device according to their

actual needs. In addition, it offers a variety of interface options such as SDL/DVI/Monitor and DisplayPort interfaces

for connecting monitors or panels. At the same time, the addition of CFast slots also provides more storage and expansion possibilities.

5PC810. SX05-00

In addition, the system unit incorporates new microprocessor technology that allows graphics to be integrated directly

onto the CPU board, further increasing the processing power and efficiency of the device. Compared to traditional

industrial equipment, the 5PC910.SX02-00 offers higher performance and more flexible configuration options.

In terms of durability, the enclosure of the equipment is specially coated to effectively prevent direct contact with

corrosive liquid substances, thus avoiding the problem of rapid deterioration of the equipment due to contact with

corrosive substances. This design enables the equipment to operate stably for long periods in harsh industrial environments.

In addition, the 5PC910.SX02-00 system unit is highly adaptable. It can be operated with or without fan units according

to the operation requirements of the equipment, which provides users with more options to adapt to different working

environments and heat dissipation needs. However, if the system unit is operating in conjunction with the fan unit, the

operator needs to regularly check the fan for wear and clean or replace it in time if the fan does not function properly to ensure the stable operation of the system.

Finally, from the point of view of use restrictions, the maximum allowable operating height that the device can operate is

about 3,000 meters above sea level, which limits its application in extremely high altitude areas to a certain extent.

However, considering that its main application scenarios are industrial environments, this limitation will not have much impact on most applications.

In summary, the APC910 system unit in slot 5PC910.SX02-002 is an industrial system unit with high performance, high

stability, and high adaptability, which can meet the requirements of various complex industrial applications.
