VE4050S2K1C0 M-series I/O Subsystem Horizontal Carriers

Operating temperature-40 to 70°C (-40 to 158°F)
Storage temperature-40 to 85°C (-40 to 185°F)
Relative humidity5 to 95%, non-condensing
Airborne contaminantsISA-S71.04-1985 Airborne Contaminants Class G3 Conformal coating
Shock10 g½-sine wave for 11 ms
Vibration1 mm peak-to-peak from 5 Hz to 16 Hz, 0.5 g from 16 Hz to 150 Hz
Hazardous area/locationATEX EEx nA IIC T4 Class 1, Div 2, Groups A, B, C, D, T4

VE4050E1C

Get your I/O subsystem up and running efficiently with the DeltaV™ horizontal mount I/O carriers. The power/controller

carrier contains internal power buses. You don’t need to use external cabling to connect the system power supply to the

DeltaV controller and the I/O interface carriers. The Subystem Horizontal Carriers modular design allows flexible installation and integrated power distribution.

Modular design allows flexible installation. A T- type DIN rail is all you need to mount the power/controller carrier into
place. The I/O interface carrier plugs on to the power/controller carrier. Simply plug your I/O terminal blocks into the carrier.
The DeltaV system’s modular design approach allows you to add I/O carriers as you need them.
