CON021/916-160 Front burner Global Supply

Description

CON021/916-160 EPRO shaft vibration sensor Eddy current sensor preprocessor Technical parameters:
Input eddy current sensor PR6422/… ~ PR6426/…
Output: The AC voltage signal superimposed on the DC voltage is proportional to the shaft vibration. Open circuit and short circuit protection; There is reverse protection. Linear range of output voltage :-4… -20V(the supply voltage is -24V);
Maximum range of output voltage: -1… -22V;
Reference voltage :-12V(symmetrical measurement range at both ends); Internal resistance :100kQ;
Response time :15us;
Accuracy (all data relative to full scale) linear error:
The preprocessor CONOX1
CONOX1/91
Connect sensor PR6422: ≤1.5%
Connect sensor PR6423: ≤1.0%
2% or less
Connect sensor PR6424: ≤1.5%
2% or less
Connect sensor PR6425: ≤6.0%
Connect sensor PR6426: ≤1.5%
2% or less
Temperature drift: zero 200mV/100K; Sensitivity <2%/100K. Time drift: 0.3% Max
Supply voltage error :<0.2%/N
Protection level: In accordance with Eex ib lC T6/ T4 preloader number
CON011 CON021/916-160
CON021/913-030CON031/914-060CON021/914-080CON011/914-100CON021
CON031/916-120CON021/916-160CON011/916-200CON031
