Name: PR9268/202-100 EPRO Shaft vibration sensor
Brand: GE
Availability: InStock

Description

PR9268/202-100 EPRO Shaft vibration sensor

[service contact information]

Tel: 18059884797 (WeChat with the same number)
QQ：3095989363
Email: sales@xiongbagk.cn
Address: Unit 2009, Chuangxiang Center, No.1733, Lvling Road, Siming District, Xiamen

① 24-hour email reply (12 hours);

③ For shipment to countries outside Asia, please contact the seller.

R9268/200-000 PR9268/201-000 PR9268/202-000 PR9268/203-000 PR9268/300-000 PR9268/301-000 PR9268/302-000 PR9268/303-000 PR9268/600-000 PR9268/601-000 PR9268/602-000 PR9268/603-000 PR9268/700-000 PR9268/701-000 PR9268/702-000 PR9268/703-000 PR9268/204-000 PR9268/205-000 PR9268/206-000 PR9268/207-000 PR9268/304-000 PR9268/305-000 PR9268/306-000 PR9268/307-000 PR9268/604-000 PR9268/605-000 PR9268/606-000 PR9268/607-000 PR9268/704-000 PR9268/705-000 PR9268/706-000 PR9268/707-000 PR9268/017-100

Features:

Used to measure absolute vibration.

Working temperature can reach 200 C.

Easy to install

High sensitivity

Rugged housing suitable for industrial applications

Waterproof protection level: IP 55 resp. IP 65

Two frequency ranges: 10 Hz-1000 Hz 4 Hz-1000 Hz

Connection safety barrier (zone 1) explosion-proof grade EEX IB II B/II C.

Is a part of MMS 6000 and MMS 3000 rotating machinery monitoring and protection system.

Application:

The absolute vibration sensors PR 9266/ .. and PR 9268/ .. series are used to measure absolute mechanical vibration in the frequency range of 10…1000Hz and 4 … 1000 Hz. The maximum amplitude of measurement can reach 2mm or 3mm (peak-to-peak). They can provide voltage signals proportional to the vibration speed. The two series of sensors provide several basic models and are widely used in many fields of industrial measurement. Rugged structure allows installation in dangerous environment. It can be applied to various turbine machines, fans, compressors, gearboxes, water pumps, coal grinders, etc. Sensors PR 9268/60 and PR 9268/70 are especially suitable for high temperature environment. This sensor has three different sensitivities, depending on the type of measuring amplifier. The high output and low impedance of the measuring coil make the sensor have strong anti-interference. It can be directly connected with MMS 3000 and MMS 6000 steam turbine monitoring and protection systems produced by epro.

Function and principle:

The absolute vibration sensors PR9266 and PR9268 are composed of a seismic block and a measuring coil supported by a spring plate. The measuring element can move in the magnetic field of a circular permanent magnet. The natural frequency of the sensor is between 4-13Hz, depending on different sensor models. When the sensor vibrates, it will produce a voltage signal proportional to the vibration speed. PR9268/… series sensors can only have one measuring direction (vertical or horizontal). The PR 9266/ .. series sensor has a lifting coil, which can be used for both vertical and horizontal measurement.

PR9266 10/11/12 Dimensions and Connection Diagram

PR9268 20/30 Dimensions and Wiring Diagram

PR9268 60/70 Dimensions and Wiring Diagram

PR9268/202-100
