350-E-P1-G1-H-E-S-C-P-2E-D-N Multilin 350 Intuitive and Innovative Feeder Protection

The Multilin™ 350 is a member of the Multilin 3 Series protective relay platform and has been designed for the protection, control and management of feeders or related applications as a primary or backup protection device. This cost-effective protective device is used to perform advanced feeder protection, control and monitoring in a drawout or non-drawout design for low, medium and high voltage applications. The 350 also offers enhanced features such as metering, monitoring and diagnostics, preventative maintenance, advanced communications and security.
Key Benefits
• Cost-effective and flexible protection and control for utility and industrial applications
• Field-proven algorithms and reliable protection to avoid unwanted trips or under-protection
• Ease of use and standardization with one-step setup and universal CT inputs

Add to quote
Category:

Description

350-E-P1-G1-H-E-S-C-P-2E-D-N Multilin 350 Intuitive and Innovative Feeder Protection

Product Description

The Multilin™ 350 is a member of the Multilin 3 Series protective relay platform and has been designed for the protection, control and management of feeders or related applications as a primary or backup protection device. This cost-effective protective device is used to perform advanced feeder protection, control and monitoring in a drawout or non-drawout design for low, medium and high voltage applications. The 350 also offers enhanced features such as metering, monitoring and diagnostics, preventative maintenance, advanced communications and security.
Key Benefits
• Cost-effective and flexible protection and control for utility and industrial applications
• Field-proven algorithms and reliable protection to avoid unwanted trips or under-protection
• Ease of use and standardization with one-step setup and universal CT inputs
• Environmental monitoring system to monitor operating conditions and plan preventative maintenance
• Advanced power system and switchgear diagnostics
• Flexible communications with multiple ports and protocols allowing seamless integration
• Integrated arc flash detection using light sensors supervised by over current to reduce incident energy and equipment damage
• Arc flash mitigation via zone inter-tripping, flex curves and multiple elements and setting groups
• Powerful security and hierarchical password control for centralized management
• Application flexibility with the use of programmable logic elements
• Drawout design simplifying, commissioning and maintenance, thereby increasing process uptime
• Increased network availability with zero failover time through IEC® 62439-3 PRP and HSR support
• Precise time synchronization through IEEE® 1588 (Precise Time Protocol (PTP)) support
• Robust design exceeding industry standards, with Automotive Grade components and advanced testing procedures such as accelerated life cycle testing
• Simplified migration of legacy MII Family relays to the 3 Series platform

350-E-P1-G1-H-E-S-C-P-2E-D-N

Product parameter

The 350 relay is a member of the 3 Series family of Multilin relays. This protective device is used to perform primary or back-up circuit protection on medium or high voltage feeders or transformers and downstream protection for utility and industrial switchgear. The 350 can be used for a wide variety of protection applications in power systems such as HV/MV or MV/LV transfomer
protection or capacitor bank protection.
The basic protection provided by this relay includes multiple phase, ground, and neutral time and instantaneous overcurrent elements for coordination with upstream and downstream devices. Additionally, the device provides essential feeder control features such as cold load pickup blocking, 2nd harmonic blocking, breaker failure, synchrocheck and autoreclose.
The robust 350 streamlines user work flow processes and simplifies engineering tasks such as configuration, wiring, testing, commissioning and maintenance. This cost-effective relay also
offers enhanced features such as diagnostics, preventative maintenance, arc flash mitigation and security

Application field

• Primary protection and control for MV and HV utility and industrial overhead or cable feeder applications
• Protection for distribution transformers of various sizes and voltage levels
• Back-up protection for various HV application and capacitor bank protection
• Advanced control applications including Cold Load Pickup, multi-shot recloser and multiple settings groups
• Protection, control and monitoring of LV Incoming feeder providing flexible communications and eliminating the need for auxiliary equipment
• Protection against corrosion and humidity required for harsh environments
