Description
Part Number DS200LPPAG1AAA
Series Mark V
Manufacturer GE General Electric
Instruction Manual GEI-100178
Product Type Line Protection Panel Board
Functional Acronym/Abbreviation LPPA
System Input Voltage 200-600 VAC
Group Revision G1
The GE Line Protection Board, DS200LPPAG1AAA, features seven jumpers and two terminal blocks with three terminals on each. The jumpers are identified as JP1 through JP7. The GE Line Protection Board DS200LPPAG1AAA also contains test points. The board is installed on standoffs on another component of the drive. The signal wires that connect to the board originate on the other component.
If you suspect that the DS200LPPAG1AAA board is not functioning properly, there are several steps you can take to determine if the board is faulty. The first step is to access the diagnostic tool contained in the drive to produce a report on the health of the functions and components. The diagnostic tools are a menu selection on the control panel. Once the diagnostic report is complete, you can view it on the control panel display or download the file to a laptop. The file can be saved, and you can compare the diagnostic results before and after your repair actions.
The module has a menu-driven interface one selection is to access the diagnostics. The other menu selection enables you to download and upload files from a laptop connected through a serial cable. Other menu selections are to access the sections of the drive configuration and edit the parameters. The parameters define the behavior of the drive during operation.
The keypad on the DS200LPPAG1AAA contains buttons that enable the operator to control the drive directly without changing the parameters. The operator can stop and run the drive and select to speed up or slow down the drive, depending on predetermined parameters.
Frequently Asked Questions about DS200LPPAG1AAA
Are there any other group revisions available for the DS200LPPAG1AAA model?
No, the only group available on LPPA models is G1, but there are differences between the module types. This model, an LPPA board, will be used in systems with input voltages in the range of 230-600 VAC. The LPPB board, which is also a Line Protection Panel board, operates in systems with input voltages in the range of 601-1500 VAC. The different input voltages are the only differences in Line Protection Panel modules in the Mark V DS200 series.
If the DS200LPPAG1AAA model malfunctions how should I go about replacing the board?
If the model malfunctions and must be replaced, then the power in which the board is installed must be removed, and wait for all capacitors to discharge. Remove the LPPA board from the cabinet and disconnect all of the cables. Be sure when disconnecting the cables that the individual wires from the screw terminal section are not removed from the connector. When removing the wiring connected to a stab terminal board, grasp the body of the receptacle and pull the acceptable free and not the wire. To remove the board squeeze the locking tabs on each of the four locking standoffs.
One of the downsides of the LPPA board is that the voltage on which the model operates is less than the LPPB board. The LPPA board accepts an input voltage of 230-600 VAC; the LPPB board will operate on an input voltage of 601-1500 VAC.
