Description
Manufacturer GE General Electric
Series Mark V
Part Number DS200SDCCG1AEC
Product Type Drive Control Card
Instruction Manual GEI-100029
The GE Drive Control Board DS200SDCCG1AEC is the primary controller for the drive. The GE Drive
Control Board DS200SDCCG1AEC is populated with 3 microprocessors and RAM that can be accessed
by multiple microprocessors at the same time.
Several tools are available for you to troubleshoot the board, if a problem arises. First, open the cabinet d
oor and view the LEDs on the board. The GE Drive Control Board DS200SDCCG1AEC is populated with t
en LEDs that are arranged in a row on the board. When the LEDs flash in a sequence across the row, it me
ans the board is operating without error. When the LEDs flash slowly, they indicate an error code from 1 to
399. When the LEDs flash faster, they indicate an error code between 400 to 1023.
Test points are available on the board. They are metal posts that you can probe with a tester to test the signal paths. This procedure can only be performed by a trained servicer and the testing equipment must be approved for the purpose and also must be calibrated for the task.
Another diagnostic tool you can use is the diagnostic tools available on the drive. The diagnostic tools are accessible from the control panel and they produce a detailed description of the performance of all the components in the drive. If a problem is found that originates on the board, you can resolve the issue and resolve it.
The diagnostics results can be downloaded from the drive to a laptop over a serial connection.
