DS200SLCCG1ACC GE

The DS200SLCCG1ACC board is a LAN (local area network) communication card developed by General Electric. This card was manufactured as a member of drive board Mark V series. Cards from this series are developed to be installed in a number of drives and exciters across the GE family. This unit specifically provides the host drive with the required processors for LAN communications. Since it was developed as a G1 version, this card includes the circuits required for both DLAN and ARCNET network connections.

Installing the DS200SLCCG1ACC board provides the host drive with both isolated and nonisolated communications circuits. An integrated LAN control processor (LCP) is the key processing point on the board. Program memory for the LCP is available in the two onboard EPROM memory modules. Interfacing using this board is performed with the on board dual ported RAM. The LCP and the drive’s connected drive control board use this space to communicate information. The board is complete with an attachable alphanumeric keypad. When connected, this 16 position display provides user access to system control settings and diagnostics.

All drive boards shipped by AX Control will be protected by a static resistant plastic bag. Do not begin device installation before all provided storage and installation parameters are reviewed. Personnel trained to handle drive boards such as the DS200SLCCG1ACC should be the only users handling the card. Please refer to the device manual and datasheet for a comprehensive wiring guide for this LAN communication board. Originally, this device was provided with technical support by the manufacturer, General Electric.

Our knowledgeable sales team at AX Control is happy to speak with you about all of your automation needs. Please contact our staff for pricing and all other information for the DS200SLCCG1ACC.
