IC694MDL940 16 point relay output module

The front of the IC694MDL940 output module has an LED indicator to show the on/off status of each output point. There is no fuse in this high voltage module. In the IC694MDL940 output module, there is a 250 volt AC isolation voltage between the field and the rack, and a 1500 volt AC isolation voltage between the backplane and the ground of the rack. The module can withstand a maximum load of 2 ampere pilot operating current per output and a maximum load of 4 ampere per common point. The minimum load required is 10 mA and the maximum surge current rated is 5 amps. The IC694MDL940 output module can be configured using Proficy Machine Edition programming software. The operating temperature should be set between 0 and 60 degrees Celsius

Add to quote
Category:

Description

About IC694MDL940

The output module of IC694MDL940 is a 16-point relay output module of AG Fanuc. This output controller module is used in conjunction with the RX3i PACSystems module. It is powerful and has several useful features. It is used to control the output load. It is rated at 2 amps for output switching. It is the RX3i series module, manufactured for industrial use. It is rated for 24 volts DC or 120/240 volts AC. The output quantity is 16, divided into 4 groups. Ac power supplies operate at a frequency of 50/60 Hertz. Output voltage ranges from 5 to 30 volts DC or 5 to 250 volts AC. Its current consumption is rated at 7 mA at 5 volt bus voltage and 135 mA at 24 volt relay voltage.

IC694MDL940

Technical Specifications for IC694MDL940

Manufacturer GE Condition 100% New Original
Brand GE Long Term Drift < 0.3%
Part Number IC694MDL940 Frequency Range 24 to 68kHz
Product Name 16 point relay output module Input Voltage Range 0 to 55 VDC
Product situation Out of production Operation Temperature -20 to 160°C
Product Package Original Package Shipping term TNT DHL FEDEX EMS UPS



It has thousands of inverter boards, capacitors, sensors, inverter fans, IGBT power modules and SCR thyristor diode GTO modules in stock.

Transportation: UPS, DHL, FEDEX, TNT, ARAMEX, EMS
Payment method: bank transfer or escrow or paypal. We accept payment in US dollars and RMB.
Delivery time: Some stock parts can be shipped within 2 days. Some are booked for 3-5 days. But high power and special parts should be weeks.

If you have any need, please feel free to contact us. Welcome to www.sauldcs.com
