IC695PSD040 power module output voltage

The IC695PSD040 is a 24 volt DC 40 watt power module from the GE Fanuc RX3i series. Built specifically for the RX3i

PACSystems family, this power module offers a standard output voltage of +5.1 volts DC, as well as the +3.3 volts DC

output voltage typically used for RX3i modules in the IC695 product line.The input voltage range of the IC695PSD040 power

supply is 18 to 30 volts DC (for startup mode) and 12 to 30 volts DC (for operation mode). The device has a surge current of

4 amps, a maximum duration of 100 milliseconds, and an output current of 0 to 6 amps or 0 to 9 amps. All outputs have ripple and noise ratings of 50 millivolts.

In addition, the IC695PSD040 power supply has an on/off switch that is located behind the door at the front of the module

and serves as an output control mechanism. The switch is equipped with a guard that prevents the user from accidentally

turning the device on or off. The terminal of the IC695PSD040 power supply accepts a wire from 14 AWG to 18 AWG with a terminal current rating of 6 amps.
