IC800SSI216 GE Servo motor controller

Description

The C800SSI216RD2 is the AgFANuc VersaMotion motor controller, which is a 180-250 VAC device with phase input,

it supports DeviceNet programming, position feedback per device, a serial port, and eight discrete inputs and outputs.

The front panel of the device also displays module status, network status, address/code, and down/reverse.

The two-character LED display allows for real-time diagnostic updates using mnemonic displays such as “OK”

“OV” (motor overvoltage,)LE(for loss of enablement,) and so on.
The C800SSI216RD2 is designed for use with a specific series of motors, which include MTR-3S45-HMTR-3S46H,

MTR-3S63-G, MTR-3S65-G, MTR-3S67-G, MTR-3T45-, MTR-3T54-H and MTR-3T55-H.

These motors have a continuous stall moment range of 32 to 150.3 inch-pounds and a rated

speed range of 1,400 to 5,300 RPM, refer to the GE data sheet for details.

IC800SSI216

More than a decade ago, GE Fanuc incorporated the Whedco lnc’s IMJ model into the S2K series, and if

you’re replacing one of these controllers, take note of the 1C800SSI216RD2, which also comes with an I

MJ)31GD-2d co-server motor controller with DeviceNet’s 16A parser feedback
The C800SSI216RD2 operates at 0 to 50 degrees Celsius. It is stored and transported at a temperature o

f -40 to 80 degrees Celsius, humidity of 5% to 95%, and the direction of the radiator must be vertical. The

unit is rated to a depth of 3,300 feet and cannot be operated at higher altitudes without consulting GE. Th

e module is mounted with a 3-inch courtyard on all sides for effective cooling.

Please contact Sunny sales@xiongbagk.cn for the best price.
