IS420ESWAH3A Ethernet module Technical parameters
IONet Switch
IS420ESWAH1A IS420ESWAH2A IS420ESWAH3A IS420ESWAH4A IS420ESWAH5A
Product Name Mark VIe IONet Switch
Mark VIe IONet
Switch
Mark VIe IONet
Switch
Mark VIe IONet
Switch
Mark VIe IONet
Switch
Life-cycle Status Active Active Active Active Active
Copper Ports
8 ports
10/100Base-TX
copper, RJ-45
8 ports
10/100Base-TX
copper, RJ-45
8 ports
10/100Base-TX
copper, RJ-45
8 ports
10/100Base-TX
copper, RJ-45
8 ports
10/100Base-TX
copper, RJ-45
Fiber Ports
1 port 100Base-FX,
multi-mode fiber,
LC-type connection
2 ports 100Base-FX,
multi-mode fiber,
LC-type connection
No fiber ports
1 port
100Base-LX10,
-mode fiber, LC-type
connection
2 ports
100Base-LX10,
single-mode fiber,
LC-type connection
Power Requirements
24 / 28 V dc, 1 A max, TB1 and TB2 provide inputs for two independent power sources that
are Diode-OR’d for redundant power
Power Supply Connector Phoenix® contact (MC 1.5/S-STF-3.81) (qty 2, Included)
Dimensions (H x W x D) 13.8 x 8.6 x 5.6 cm (5.4 x 3.40 x 2.20 in)
Copper Cables Cat 5e UTP cable with RJ-45 connectors (8P8C)
Cooling Convection cooled
Safety Rated Non-interferring
Hazardous Locations
Capability
Class 1, Div 2 / Class 2, Zone 2 / ATEX
For ratings and further details, refer to the Mark VIeS Functional Safety System Equipment in Hazardous
Locations (HazLoc) Instruction Guide (GEH-6861).
G3 Compliant Yes
Ambient Operational
Temperature
-40 to 70°C (-40 to 158 °F)
Storage Temperature -40 to 85°C (-40 to 185 °F)
Mounting Method DIN-rail mounted with separately purchased mounting clip
Switch Replacement
Part Number
IS420ESWAH1A IS420ESWAH2A IS420ESWAH3A IS420ESWAH4A IS420ESWAH5A
