F3 DIO 20/8 02 Safety related controller HIMA

Product details:

The safety-relevant HIMatrix controller system can be mounted on mounting pedestals or in enclosed situations

such as control stations, junction boxes and control racks. They have been developed to comply with

applicable EMC, climate and environmental standards. These criteria can be found in Chapter 9 Operating Conditions, as well as in

In the manual for the HIMatrix system, it must be followed. The protection level of the HIMatrix device

(IP 20) can be enhanced to meet specific requirements by installing the table housing in the sui-. However, the heat dissipation (see Chapter 3.3) must be checked
device
All equipment must be installed horizontally (refer to front panel) to ensure adequate ventilation. Installation

in a vertical position requires additional measures to ensure adequate ventilation. Refer to the relevant manuals

for sizes of the various devices. The minimum distance between HIMatrix devices and other manufacturers’ devices is also as follows for cabinet walls
• Vertical minimum 100mm,
• About level. 20 mm(set by F60 fastening strap). Mounting space (rack height) must also be considered to

connect the inputs and outputs that connectors use to communicate (see Chapter 3.2.3 Mounting Height).

Part Number: August 20th, 2002 F3

Manufacturer :HIMA

Status: Available

Product type: security-related controller

Full description :HIMA 8/20/02 F3 HIMatrix safety-related controller

Product description

The safety-relevant F3 DIO 20/8 02 Remote I/O is a compact metal-clad system with 20-way digital input and 8-way digital output.

Remote I/O is available for a variety of models at SILworX and ELOP II plants, with the remote I/o connected to a separate

HIMax or HIMatrix controller via safeethernet. They are used to extend the I/O level, but cannot run any user programs alone.
