S70602-NANANA S700 Servo Drives

Features

• CE, UL, TÜV safety tested
• Operation directly from grounded 110 to 480 VAC, 1 or 3-phase, 50 to 60 Hz lines
• Models with maximum continuous output current from 1.5 to 72 Amps RMS/phase
• Safe Torque Off (STO) function onboard
• Safety expansion cards available with SIL2 or SIL3 safety functions such as SDI, SLS, SS1, SS2, SBC, SBT and more
• EtherCAT® and CANopen bus communication onboard
• Legacy bus support including PROFINET, DeviceNet, PROFIBUS DP, SERCOS II and RS232
• Single Cable Feedback SFD3 and Hiperface DSL
• Slot for MMC memory card for backup and copy of parameters and firmware
• Optimized resolver interface
• Autotuning
• Cogging suppression
• Fastest feedback evaluation on the market

Benefits

• High-speed current, speed and position control result in higher machine cycle rates
• Safety functions SIL2 / SIL3 increase machine availability
• IEC 61131 macro programming language inside makes motion flexible
• Multi-interface and multi-feedback features provide compatibility with all standard controllers and feedback systems, reducing the need to stock multiple drive types
• Onboard EMC filters and integrated power supply and brake resistor enable smaller switchgear cabinets
• Memory card for parameter and firmware updates, autotuning features and connectors for all connections facilitate faster setup

The S700 is a digital servo drive with extended functionality that is ideal for complex drive tasks. It incorporates

onboard Ethernet connectivity for use with EtherCAT® and SynqNet™, and the optional MMC memory card enables

parameter records and firmware to be easily backed up in the field. A Safe Torque Off function is standard, and other

safety functions can be added. Single Cable feedback with both SFD3 and Hiperface DSL is also supported.
