PXIE-5105 8-Channel PXI Oscilloscope NI

Description

PXIE-5105 8-Channel PXI Oscilloscope NI

The National Instruments PXIe-5105 (Part Numbers: 783590-01, 783590-02, 783590-03)

High-Resolution Digitizer highlights eight 60 MS/s simultaneously tested voltage input channels with

12-bit resolution, 60 MHz bandwidth capacity, and up to 512 MB of memory in a smaller, 3U PXI/PXI Express,

or PCI gadget. The NI PXIe-5105 uses the National Instruments Synchronization and Memory Core (SMC)

engineering, so the user can join numerous gadgets to develop 136 phase-coherent channels in a single NI PXI

chassis. The user can also synchronize the PXIe 5105 with other analog and digital instruments to make mixed signal test frameworks.

The NI PXIe 5105 Digitizer is perfect for an extensive variety of uses, including: ultrasonic nondestructive test

(NDT), medical imaging, scientific research, military/aviation, and consumer electronics.

PXIE-5105

The NI device is run using the NI-SCOPE driver software, which is compatible with software packages/application

development environments (ADEs) such as LabVIEW, LabWindows/CVI, Measurement Studio,

Microsoft Visual C/C++, and .NET (C# and VB.NET). The device hardware can be configured using the

Measurement & Automation Explorer (MAX) tool. It has a recommended warm-up time of 15

minutes and should be calibrated at least once every two years.

For time and frequency analysis, this Oscilloscope offers:

• 60 MHz input transmission capacity with anti-alias and noise filters

• 72 dBc spurious free dynamic range (SFDR), Eight 60 MS per second, and 12-Bit Input Channels

• Independent channel-selectable 50 mVpp to 30 Vpp input

• Independent channel-selectable 50 Ω or 1 Mω input impedance

• 2-year alignment interim and 0 to 55 ° C working temperature and a deep onboard memory

• 16, 128, or 512 MB of locally available memory

• Capture in excess of 1 million triggered waveforms in various record mode, with equipment trigger rearming

• Stream information persistently from installed memory to host memory or disk.
