BASLER A404K High performance industrial camera

A404K
DISCONTINUED BY MANUFACTURER
INDUSTRIAL CAMERA
2352 (H) X 1726 (V) (4059552 PIXELS)
48 FPS (IN 4 TAP MODE)
96 FPS(IN 8 TAP MODE)
PROGRESSIVE SCAN
MONO
54DB
12 VDC 10%MAX 9.0 W @ 12 VDC

Industrial camera A404K is generally installed on the machine pipeline instead of human eyes to do measurement and judgment, through the digital image capture target converted into image signals, transmitted to the special image processing system, image system on these signals for a variety of operations to extract the characteristics of the target, and then according to the discriminant results to control the action of the equipment in the field.
1. Usually, you first need to know the system accuracy requirements and camera resolution, which can be obtained by the formula:
X direction system accuracy (X direction pixel value)= Field of vision (X direction)/CCD chip pixel number (X direction)
System accuracy in Y direction (pixel value in Y direction)= field of vision (Y direction)/ pixel number of CCD chip (Y direction)
