Description
Product Overview
The EATON XVS-440-10MPI-1-1U represents Eaton’s flagship compact variable frequency drive (VFD), engineered for precision motor control in space-constrained industrial applications. This 10HP (7.5kW) drive integrates advanced sensorless vector control with built-in multi-protocol communication (PROFINET, EtherNet/IP, Modbus TCP) in a 1U chassis height, delivering 150% overload capability for demanding starting torque scenarios. Designed for HVAC pumps, conveyor systems, and material handling equipment, the EATON XVS-440-10MPI-1-1U achieves ±0.5% speed regulation without encoder feedback while reducing energy consumption by up to 60% compared to throttling methods. Its IP20-rated enclosure features removable control terminals and front-access cooling for simplified maintenance in control cabinets where accessibility is critical.
## Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | XVS-440-10MPI-1-1U |
| Manufacturer | EATON |
| Product Type | Variable Frequency Drive |
| Rated Power | 7.5 kW (10 HP) |
| Input Voltage | 3-Phase 380–480V AC ±10% |
| Output Current | 18 A (150% overload for 60s) |
| Control Method | Sensorless Vector Control (SVC) |
| Speed Regulation | ±0.5% (no encoder) |
| Switching Frequency | 2–16 kHz (adjustable) |
| Communication | PROFINET, EtherNet/IP, Modbus TCP (embedded) |
| I/O Configuration | 4 DI, 2 DO, 2 AI, 1 AO |
| Braking | 150% dynamic braking (built-in) |
| Protections | Overcurrent, Overvoltage, Motor Stall, Phase Loss |
| Enclosure Rating | IP20 (NEMA/UL Type 1) |
| Dimensions | 185 × 73 × 200 mm (W×H×D) |
| Weight | 2.8 kg |
| Operating Temp | -10°C to +50°C (40°C derating) |
## Key Features and Advantages
Space-Optimized Performance
The 1U height design saves 60% panel space versus standard drives, while front-access cooling fins eliminate rear clearance requirements. Dual-rated 18A output enables direct starts for high-inertia loads like crushers or mixers without oversized drives.
Intelligent Energy Management
Auto-tuning algorithms optimize V/f curves in <30 seconds, reducing motor losses by 15%. Power factor correction (0.98 lagging to leading) minimizes reactive power penalties. Built-in energy meter tracks kWh consumption for ISO 50001 compliance.
Eaton-XVS-440-10MPI-1-1AD
Seamless Integration
Embedded MPI communication supports simultaneous PROFINET and Modbus TCP connectivity – ideal for hybrid PLC environments. DriveLogix™ functionality allows local control logic execution, reducing PLC scan time by 40%.
Maintenance Simplified
Quick-release terminal blocks enable wiring without dismounting the drive. SD card slot clones parameters in <10 seconds. Predictive health monitoring alerts on capacitor aging or heatsink overtemperature 30+ days pre-failure.
## Application Areas
Warehouse Automation: Synchronizes pallet conveyor networks via PROFINET IRT with ±5ms axis synchronization, eliminating product jams.
HVAC Systems: Controls centrifugal chillers with PID sleep mode, cutting pump energy by 45% during low-load periods.
Food Processing: Washdown-ready stainless steel option (XVS-440-10MPI-1-1U-SS) withstands high-pressure spray in meat packing plants.
Mining Ventilation: Regulates fan airflow with automatic belt slip detection, triggering redundancy protocols during critical events.
## Related Products
- XVS-440-10MPI-1-1U-SS – Stainless steel variant
- XVS-440-10MPD-1-1U – PROFIBUS DP version
- XVC-22.0K-1 – 22kW expansion drive
- EATON DG1 – Dynamic braking resistor (for high-inertia loads)
- EATON XNMC-01 – Network module (CANopen/J1939)
- EATON XVF-OPP – Operator panel (remote control)
- XVS-440-05MPI-1-1U – 5HP compact model
- EATON XVS-FILTER – EMC input filter (EN 61800-3 Cat. C4)
- EATON XVS-REACTOR – Line reactor (THID <8%)
- XVS-440-10MPI-2-1U – 10HP with 2U cooling capacity
