KV-7500 KEYENCE Built-in CPU unit

Description

KV-7500 KEYENCE Built-in CPU unit

Model KV-7500
Type CPU unit
General Specifications Power supply voltage KV-5000/3000 series using extension unit system: 24 VDC (± 10%)
KV-7000 series system with only extension unit: 24 VDC (-15% /+ 20%)
Using the ambient temperature KV-5000/3000 series using the extension unit system: 0 to +50 °C (no icing)
KV-7000 series system with only expansion units: 0 to +55 °C (no icing)
Using ambient humidity KV-5000/3000 series using expansion unit system composition: 10 to 95%RH (no condensation)
KV-7000 series system with only expansion units: 5 to 95%RH (no condensation)
Storage ambient temperature KV-5000/3000 series using extension unit system: -20 to 70 °C
KV-7000 series system with only extension units: -25 to 75 °C
Storage environment humidity KV-5000/3000 series When using expansion unit system composition: 10 to 95%RH (no condensation)
KV-7000 series system with only expansion units: 5 to 95%RH (no condensation)
There is no large amount of dust and corrosive gas in the operating environment
Use below 2,000 m above sea level
Noise resistance above 1,500 Vp-p, pulse width 1 µs,50 ns (obtained by interference simulator), compliant with IEC standards (IEC61000-4-2/3/4/6)
Withstand voltage 1,500 VAC, 1 min (between power terminals and input/output terminals and between all external terminals and housing)
Insulation resistance above 50 MΩ (500 VDC megohm meter measures between power terminals and input and output terminals and between all external terminals and housing)
Impact resistance acceleration 150 m/s2, action time 11 ms, X,Y,Z direction twice
Pollution Level 2
Vibration resistance intermittent vibration frequency 5 to 9 Hz single noise 3.5mm *1
Frequency 9 to 150 Hz acceleration 9.8m /s2*1
The frequency of continuous vibration is 5 to 9 Hz, and the monofilm is 1.75 mm*1
Frequency 9 to 150 Hz acceleration 4.9m /s2*1
Performance specification Operational control mode stored program mode
I/O Control Mode Refresh mode
Programming language extension ladder diagram, KV script, mnemonic
Number of instructions Basic instructions: 80 types, 181 sentences
Application instructions: 50 kinds of 67 sentences
Operation instructions: 125 kinds of 318 sentences
Extended instructions: 76 kinds of 131 sentences
Total: 331 kinds of 697 sentences
Instruction execution speed Basic instruction: minimum 0.96 ns
Application instruction: Minimum 5.75 ns
Double precision floating decimal command: min. 58 ns
The CPU memory capacity is 64 MB
The program capacity is about 1,500k steps
Maximum number of units installed 16 (KV-7000 series extension unit only)
48 sets (KV-7000 series extension unit, KV-5000/3000 series extension unit (when using extension unit (KV-EB1))
Maximum I/O points at 3,072 points (KV-EB1S/KV-EB1R: when 2 units are used and 64 points are used)
Bit soft element input relay R total 16,000 points 1 bit
Output relay R
Internal auxiliary relay R
Link relay B 32,768 point 1 bit
Internal auxiliary relay MR 64,000 point 1 bit
Latch relay LR 16,000 points 1 bit
Control relay CR 1,280 point 1 bit
Word soft component timer T 4,000-point 32-bit
Counter C
Data memory DM 65,535 points 16 bits
Extended Data storage EM
Files are stored in the current group FM 524,288 point 16 bit
Serial number connection mode ZF
Link register W 32,768 points 16 bits
Temporary Data memory TM 512 points 16 bits
Address register Z 12 point 32 bits
Control memory CM 6000 points 16 bits
Note, label host storage number soft component note about 224,000
The number is about 285,000
Power outage standby function program memory flash ROM, can be rewritten 10,000 times
Soft component non-volatile RAM
Calendar-timer backup capacitor for about 15 days (25 °C)
(About 5 years (25 °C) when using KV-B1 (battery))
Self-diagnosis function CPU exception, RAM exception, other
Internal consumption current below 200 mA
Weight CPU unit: about 270 g
Bus connection unit: about 130 g, KV-B1 (battery) : about 10 g
