Description
REF615A_E HAFAABAAABE1BCA1XE ABB Microcomputer protection device
Technical Requirements:
REF615A_E HAFAABAAABE1BCA1XE ABB Microcomputer protection device
The microcomputer protection device is composed of high integration, bus-less chip, high precision current and voltage transformer, high insulation strength outlet intermediate relay, high reliability switching power module and other components
In addition to the advantages of microcomputer protection, compared with similar products, the microcomputer protection device has the following characteristics:
(1) Complete varieties: microcomputer protection devices, varieties are particularly complete, can meet the various types of substation equipment protection requirements, which provides great convenience for the substation design and computer networking.
(2) The hardware adopts the latest chip to improve the technical advancement, the CPU adopts 80C196KB, the measurement is 14-bit A/D conversion, the analog input loop is as many as 24, the acquired data is processed by DSP signal processing chip, the high-speed Fourier transform is used to obtain the fundamental wave to the 8th harmonic, the special software automatically corrects. Ensure the high precision of measurement. By using dual-port RAM and CPU to transform data, a multi-CPU system is constituted. CAN bus is used for communication. It has the characteristics of high communication rate (up to 100MHZ, generally running at 80 or 60MHZ) and strong anti-interference ability. Through the keyboard and LCD display unit can be convenient for field observation and various protection methods and protection parameter setting.
(3) The hardware design adopts special isolation and anti-interference measures in the power supply, analog input, switch input and output, communication interface and so on. The anti-interference ability is strong. In addition to the centralized panel, it can be directly installed on the switch cabinet.
(4) The software is rich in functions. In addition to various measurement and protection functions, it can complete fault recording (1-second high-speed fault recording and 9-second dynamic fault recording), harmonic analysis and small current grounding line selection by cooperating with the upper processing computer.
(5) CAN choose RS232 and CAN communication mode, support a variety of remote transmission protocols, convenient and a variety of computer management system networking.
(6) The wide temperate zone background 240×128 large screen LCD LCD display, easy to operate, beautiful display.
(7) High integration, small volume, light weight, easy to centralized panel installation and scattered installation on the switch cabinet.
We have hundreds of millions of inventory, product parts tens of thousands, if you are interested in our products can contact us at any time.
