5136-PFB-VME Profibus interface card

Description

Molex/Woodhead/SST 5136-PFB-VME Profibus interface card Yes
Act as DP slave, act as DP master, and send and receive FDL(Layer 2) messages. the
Stick to all of these patterns while operating. The card supports 9.6K, 19.2K, and 93.7
5K, 187.5K, 500K, 750K, 1.5M, 3M, 6M and 12M baud
Quasi-profibus baud rate. The card has an onboard Intel i960 processor and 512 bytes
Local RAM for processing communication protocols and data formats in shared RAM.

5136-PFB-VMEProfibus interface card

The card has an additional 256 kilobytes of RAM, which is shared with the host as a single block of 256 kilobytes (linear addressing mode) or as one of 16 16 kilobyte pages (paging mode). In-page mode
The host determines which page of shared RAM is mapped to the host memory by writing to a register on the card. This memory block contains all the application software used to run on the interface card and host
Tables and buffers that pass information between pieces. This method ensures a fast and easy connection between the host and the card software. In addition, the card has 512 kilobytes of partitioned flash memory for storing programs and accessories
Set data. ProfiBus configuration information can also be stored in flash memory.
