MVI69E-MBTCP  Enhanced Communication Module

To get the most benefit from this User Manual, you should have the following skills:
• Studio 5000 Logix Designer ®
: launch the program, configure ladder logic, and transfer the ladder logic to the processor
• Microsoft Windows: install and launch programs, execute menu commands, navigate dialog boxes, and enter data
• Hardware installation and wiring: install the module, and safely connect Modbus and CompactLogix

devices to a power source and to the MVI69E-MBTCP module’s Ethernet port

The MVI69E-MBTCP module requires the following minimum hardware and software
components:
• Rockwell Automation CompactLogix® processor (firmware version 10 or higher), with
compatible power supply and one free slot in the rack, for the MVI69E-MBTCP
module.

MVI69E-MBTCP

• The module requires 500 mA of available 5 Vdc power
• Rockwell Automation Studio 5000 programming software version 16 or higher
• Rockwell Automation RSLinx® communication software version 2.51 or higher
• ProSoft Configuration Builder (PCB) (included)
• ProSoft Discovery Service (PDS) (included in PCB)
• Pentium®
II 450 MHz minimum. Pentium III 733 MHz (or better) recommended
• Supported operating systems:
o Microsoft Windows® 10
o Microsoft Windows® 8
o Microsoft Windows® 7
o Microsoft Windows Vista
o Microsoft Windows XP Professional with Service Pack 1 or 2
• 128 Mbytes of RAM minimum, 256 Mbytes of RAM recommended
