Description
Product details:
Part Number | SST-PB3-REM-CC |
Manufacturer | Woodhead |
Product Type | SST Linking Device EIP to PFB |
Applicable Allen-Bradley Series | ControlLogix |
Channel | 1 |
Ports | 2 |
Network Connection Type | PROFIBUS D-Sub Female (9 pin) |
Slave | PROFIBUS DPV0 |
Option | Conformal Coated |
Weight | 550 kg |
The SST-PB3-REM module is an SST Profibus remote module designed by Woodhead. This remote module is a linking device between EIP and PFB. The module uses a DIN rail for mounting. The slave of this module is a PROFIBUS DPV0 unit. The network connection type used in this module is the PROFIBUS nine pinned D-sub female connector. This module is compatible with Allen-Bradley peripheral devices. The module weighs 550 grams. The SST-PB3-REM module is a linking device designed for PROFIBUS-V0 and DP-V1 master-slave use with the Ethernet/IP adapter. The module is powered using a 24 Volts DC supply. The module can support up to 5 listener connections. It supports explicit messaging for retrieving the status and diagnostics information as well as the I/O data.
The front panel of the SST-PB3-REM module is equipped with a screw terminal for a 24 Volts DC power supply connection. It contains a support plate for fixing the module directly to a DIN rail mounting base. The RJ 45 connectors for the Ethernet link are also placed on the front panel of the module. To display various status updates, the module has 4 LED indicators. They include the PROFIBUS fault detector, system fault detector, Profibus state, and the PLC Run/Prog state LEDs. The SST-PB3-REM module may face IP duplication conditions. To avoid this problem, it is necessary to identify all the existing Ethernet devices in the network and assign IP addresses to the new device. The Profibus configuration tool can be used to program and set the IP address. The module is also equipped with rotary switches on the back of the module.
