Product details：

The 45C322 unit is a power supply module that Reliance Electric was responsible for bringing to the market. The 45C322 power supply has an Amperage rating of 50 Amps, a Voltage rating of 120/240 Volts, and 50/60 Hertz. The 45C322 power supply has a total of 3 card slots.The 45C322 power supply is a single circuit board that is housed within a plated steel and anodized aluminium heat sink enclosure. This module has voltages that are designed to provide power to the module logic circuitry with the connected rails. In addition to that, the voltages are also provided to power to the logic circuitry contained onto the cards which have the ability to be placed directly inside of the card rack.

45C322

On the faceplate of the 45C322 power supply, there are three LED status indicators. The first status indicator light is labeled as the “AC POWER ON” light. When this light is on, it indicates that incoming power is being supplied to the power supply that is within the specified ranges. The second status indicator is labeled as the “POWER SUPPLY READY” light. When on, this indicates that the power supply is producing the required voltages within the specified ranges. Lastly, there is the status indicator labeled “SYSTEM READY.” When on, this light indicates that there are no faults within the system.
