VT-MACAS-500-10/V0/  Analog position control module

VT-MACAS-500-10V0I

With this controller module, an integrated analog position measurement system (potential
Simple position or speed control of the Bosch Rexroth servo hydraulic cylinder. because
The whole signal processing is an analog process, and the module is only designed to realize closed-loop control
The necessary elements of the system. Thus lower drive costs can be achieved. In addition, module
The block has the feature of internally switching to speed control mode (panel operation), in
In different cases, the signal is voltage type or current type according to the command value and actual value
There are different product models corresponding.
Position control
The position of the control value and the actual value will be compared after the controller calculates the deviation
Will be transmitted to the valve amplifier. If the input signal suddenly changes, the system will
React with maximum dynamic functionality. Accelerate or brake the load
The time is limited by the available power gain or system gain. Due to oblique use
With the slope function as an input value, the load will move more smoothly.
