Description
140CRP93100 Schneider RIO header adapter
The Modicon 140CRP93100 RIO front-end adapter module was manufactured by Schneider Electric for the Modicon Quantum platform to meet the needs of automated production lines.
140CRP93100 Used for remote I/O installation applications. It plays a crucial role in the Quantum remote I/O architecture solution. You will benefit from the module’s I/O branching architecture, higher I/O capacity, and connectivity with existing Modicon I/O accessories, providing you with the best remote I/O connectivity.
140CRP93100 Single-cable RIO head adapter module highlights
Modicon quantum automation platform
Architecture Type – Remote I/O
Single core cable
The S908 bus
Connected in the quantum CPU front-end module
Description: Quantum Rio head adapter (Max. 1) (1)
Cable – Single coaxial
Required bus current – 600mA
Power consumption – 3 W
advantage
Modicon 140CRP93100is an integral part of the Ethernet RIO architecture. It is part of the simple chrysanthemum ring, also known as the chrysanthemum chain ring road. The simple Daisy ring consists of a local Quantum Ethernet branch and a Quantum or Modicon X80 Ethernet RIO branch, containing a CRA branch adapter using 140CRP93100 as the RIO header adapter.
How do I use 140CRP93100
You must install and use the MA0185100 T-connector 10 because it is required for every I/O branch on your system. The T-connector is needed because it allows you to electrically isolate the branch from the mainline cable and protect the system from any possible impedance mismatch. In addition to impedance issues, it is a safety net against cable disconnection. A minimum signal strength of 14 dB is required between the trunk cable and each I/O lead-in.
When the signal on the trunk line passes through the T-connector, the loss is less than 1db. The head-on RIO CPU might have a total of 35 dB. The entire wiring system must not exceed this allowable architectural limit.
If your system needs high availability, Schneider Electric can provide you with a solution; Use redundant cables to prevent cable breakage. It also prevents any possible damage to the connector. This way, when two cables are connected between the host and each branch, the first cable may break, but will not interrupt the communication. If you happen to have a cable break, you will notice that the status bit is set to 1 when this happens.
This will indicate to you that there is a problem drop or that the cable has some kind of malfunction. If you are interested in preventive maintenance, you will find that counter values are also provided. This applies to all communication transactions for all branches. If you find a high counter value on the cable in any particular drop, this may indicate a problem with the connection. With this high level of forethought, you will be able to identify work that will correct the problem and then be able to initiate a scheduled time to react before dealing with unnecessary downtime. This will translate into savings for you. Saving time and energy will definitely save you money.
